Xerox WorkCentre 5020 Service Documentation

July, 2007
2-13
WorkCentre 5020
Status Indicator RAPS
Initial Issue
C8-1
Error Name
F/O#1 SNR Static JAM
Explanation
Tray1 Feed Sensor ON is detected during standby.
I/O Diagnostic Codes (How to Enter the Diagnostic Mode)
[08-07] Tray1 Feed Sensor
Check Items
• Tray1 Feed Sensor dirty and Sensor Actuator deformed or damaged
• Foreign matter, burrs, or paper in the paper path
• Check that the following wires are connected securely with good electrical contact. If there is no problem, replace the Tray 1 Feed Sensor
(PL 2.5) (REP 2.5.1).
– Wire between Tray 1 Feed Sensor J158-3 ( P/J158) and STM PWB J501-6 ( P/J501)
– Wire between Tray 1 Feed Sensor J158-2 and STM PWB J501-7
– Wire between Tray 1 Feed Sensor J158-1 and STM PWB J501-8
• Replace the AIOC PWB (PL 8.1) (REP 8.1.1).
O -
CH8.1
Figure 1
C8-2
Error Name
F/O#2 SNR Static JAM
Explanation
STM Feed Sensor ON is detected during standby.
I/O Diagnostic Codes (How to Enter the Diagnostic Mode)
[08-06] STM Feed Sensor
Check Items
• STM Feed Sensor dirty and Sensor Actuator deformed or damaged
• Foreign matter, burrs, or paper in the paper path
• Check that the following wires are connected securely with good electrical contact. If there is no problem, replace the STM Feed Sensor (PL
11.5) (REP 11.5.1).
– Wire between STM Feed Sensor J172-3 ( P/J172) and STM PWB J542-6 ( P/J542)
– Wire between STM Feed Sensor J172-2 and STM PWB J542-7
– Wire between STM Feed Sensor J172-1 and STM PWB J542-8
• Replace the STM PWB (PL 11.5) (REP 11.5.2) and the AIOC PWB (PL 8.1) (REP 8.1.1) in that order.
O -
CH8.2
Figure 2
E0-1
Error Name
CPM Image Lost
Explanation
During a copy job in CMP Priority Mode, it is detected that the paper containing an image cannot be output after the image is deleted.
Check Items
Press the [Stop] button on the Control Panel.
O - -
Error
Code Error Name/Explanation/I/O Diagnostic Codes/Check Items
Record in
Error Log RAP BSD
