July, 2007
6-35
WorkCentre 5020
General Procedures
Initial Issue
GDI: not supported.
Timing of Count-up
MCU increments the billing counter when the trail edge of the paper passes the Exit Sensor.
The number of counter increments is as follows:
Electrical/Mechanical Characteristics
Electrical Characteristics
*Power consumption is specified assuming full configuration.
Rated Power Consumption
[GDI]
TEC Method (New E-Star)
Machine Size/Weight
The machine specified below does not include a drum and toner cartridge.
1. Size
[Optional Devices]
Size of Package: 710x660x716 (mm)
2. Weight
Table 7
Paper size Number of counter increments
Billing Life
A3, B4, 8K, 11x17, Non-fixed 1 2
A4 or less (A4, Letter, ....) 1 1
Table 8
Input Voltage
(VAC)
Frequency
(Hz)
Rated input cur-
rent Max (A)
Power Con-
sumption*
Spec (VA)
Sleep Mode
(Off Mode)
Reference
220 - 240V 240+10%
220-10%
50/60+/-3 Hz 6A 1320VA (Max) 6 W (Max)
110 - 120V TBD TBD TBD TBD TBD
Table 9
Mode Power consumption
In Low Power Mode DC: 43W or less
CP: 107W or less
In Sleep Mode (Off Mode) DC: 6W or less
CP: 20W or less (TBD)
At operation
(During printing operation)
110V
12A, 1320VA (Max)
220/240V
6A, 1320VA (Max)
Table 10
Config TEC
GDI Network
DC20 3.0Kwh -
CP20 6.0Kwh -
Table 11
Type Width (mm) Depth (mm) Height (mm)
IOT 595+/-5 532+/-5 505+/-5
IOT+IIT (Platen Glass) 595+/-5 532+/-5 528+/-5
Table 12
Width (mm) Depth (mm) Height (mm)
STM (500 Sheets) 551+/-5 522+/-5 130+/-5
Stand 551+/-5 506+/-5 385+/-5
Table 13
Main body Configuration
Platen: Net weight (includ-
ing toner cartridge)
33.02 Kg Platen/IIT/MSI/Std Tray (250sheets) including
toner cartridge
Gross weight (with Pack-
age)
48.5Kg
(Reference)
STM 8.8 Kg Optional tray: 500sheets
Toner cartridge 1.2 Kg
Net weight (full configura-
tion)
38.0 Kg TBD IIT/MSI/Std Tray (250sheets) including toner car-
tridge
Stand 18 Kg TBD
