July, 2007
3-11
WorkCentre 5020
Image Quality
Initial Issue
Specification
[System] IOT + IIT
[DC] IOT + IIT
Table 2 Copy Alignment: Specification
Item
Specification
SYSTEM
Application
Lead Edge Registration (mm) +/- 2.90
Side Edge Registration (mm) +/- 3.40
Lead Skew (mm) +/- 2.30 280 mm
Vertical Ratio (%) 100% +/- 1.40 400 mm
Horizontal Ratio (%) 100% +/- 1.40 280 mm
Perpendicularity (mm) +/- 3.40 400 mm
Linearity (Vertical) (mm) +/- 2.00 400 mm
Linearity (Horizontal) (mm) +/- 1.40 280 mm
Linearity (Skew) (mm) +/- 1.42 280 mm
Parallelism +/- 3.70 400 mm
Table 3 Copy Alignment: Specification
Item Specification Measurement Length
Simplex MSI
Skew H +/-1.9 +/-2.2 200mm
Perpendicularity +/-2.8 +/-3.0 400mm
Linearity: V 1.4 -- 400mm
Linearity: H 1.4 -- 280mm
Linearity: D 1.4 -- 283mm
Registration: Lead +/-2.4 +/-3.1
Registration: Side +/-3.0 +/-3.2
Magnification: V (%) +/-0.95 (100%)
+/-1.16 (50%-99%)
+/-1.47 (101%-200%)
-- 400mm
Magnification: H (%) +/-0.95 (100%)
+/-1.16 (50%-99%)
+/-1.47 (101%-200%)
-- 280mm
