Xerox WorkCentre 5020 - Loading in the Document Feeder

July, 2007
3-12
WorkCentre 5020
Initial Issue
Image Quality
Figure 1 Copy Alignment Measurement Positions (Test Pattern STP3600)
2. Image Quality
How to measure
Make a copy of the Test Pattern 499T247 (A3) and measure. See Table 5 for specifications.
Table 4
Item How to measure (Refer to Figure 2)
Text/Image Density
(100%/Normal mode only)
Measure the 0.7G line image (10) at 3 locations.
Determine the maximum and minimum mean value measured
(within the same copy).
