Xerox WorkCentre 5020 - Page 62

July, 2007
3-18
WorkCentre 5020
Initial Issue
Image Quality
Strobing (28mm or 14mm Pitch Density)
Figure 2 Strobing (28mm or 14mm Pitch Density)
Cause
1. Developer Magnetic Roll bias.
Action
1. Replace the Drum Cartridge (PL 4.1) (REP 4.1.1).
