Xerox WorkCentre 5225 Service Manual

February, 2008
6-13
WorkCentre 5225, 5230
IOT NVM List
General Procedures
Launch Version
Chain 744-xxx FUSER
742-087 MPT Width of Universal-size paper - 39~247 1mm “89 - 247"=”139mm - 297mm” This is a temporary value specified from Controller. It is
cleared when the power supply is turned off or IOT resets.
742-102 MPT- First digit of length of Universal-size - 0~4 100mm
This is a temporary value specified from Controller. It is cleared when the power supply
is turned off or IOT resets.
742-102 MPT Last 2Dig of length Universal-size - 0~99 1mm
Table 7 TRAY
Chain-Link Name Default Range 1 Count Remarks
Table 8 FUSER
Chain-
Link
Name Default Range 1 Count Remarks
744-006 Fuser Standby Lamp ON Temp 45 0~99 1 deg.C Nominal=175 deg.C
744-010 Fuser Standby Lamp OFF Temp 20 0~99 1 deg.C Nominal=180 deg.C
744-043 Fuser C1 Ready Temperature-(T-READY) 25 0~70 1 deg.C Nominal=155 deg.C
744-061 Fuser Low Run Temperature-(T42) 15 0~40 1 deg.C Nominal=15 deg.C
744-065 Fuser OHP Run Temperature-(T43) 15 0~40 1 deg.C
744-080 Fuser SSTSctrlExceTM(t13) 30 0~99 1sec Nominal=30sec
744-081 Fuser SSTSctrlExceAppP(M) 10 0~99 1page Nominal=10pages
744-133 Fuser WU STRT T70(ForSB2) 0 0~99 1 deg.C Nominal=80 deg.C
744-134 Fuser Standby 2 On Temp(T71) 60 0~70 1 deg.C Nominal=190 deg.C
744-135 Fuser Standby 2 Off Temp(T72) 41 0~70 1 deg.C Nominal=191 deg.C
744-136 FSR WU STRT T70 (From V113700) 59 0~80 1 deg.C Nominal=59 deg.C
744-180 Fuser Flicker Lamp On TM 7 0~99 1.5ms Nominal=10.5 ms
744-181 Fuser Flicker Lamp Off TM 13 0~99 1.5ms Nominal=19.5 ms
744-182 Fuser Lamp Change t8 15 0~99 40ms Wave Control Time (For Flicker Precycle, Cycle) 600ms
744-183 Fuser Lamp Change t9 30 0~99 40ms Wave Control Time (For Flicker Stby) 1200ms
744-184 Fuser Lamp Change t10 12 0~99 40ms Wave Control Time (For Flicker Warm Up) 480ms
744-220 Fuser Reset FuserOverTemp 0 0~99 - 0: Reset, 1: FS1 Detected over temp, 2: FS2 Detected over temp, 3: ON time fail, 5: Cold
Sagging fail, 7: PR temperature rising fail (only reset is possible in the diagnostics mode),
8: On time fail (detects anomalous high temperature)
744-301 Fuser Very Low Tmp T80 15 0~30 1 deg.C Nominal=15 deg.C
744-302 Fuser Very Low Tmp T81 10 0~30 1 deg.C Nominal=180 deg.C
744-303 Fuser Very Low Tmp T82 0 0~20 1 deg.C Nominal=190 deg.C
744-304 Fuser Very Low Tmp T83 15 0~35 1 deg.C Nominal=175 deg.C
744-305 Fuser Very Low Tmp TR2 30 0~40 1 deg.C Nominal=180 deg.C
744-306 Fuser Very Low Tmp tP2 10 0~99 1sec Nominal=10sec
744-932 U4_2_CHK_FLG 0 0~1 U4-2 confirmation function. 0: Enable, 1: Disable
744-933 U4_2_FSR_CTL_STATE 0 0~99 FSR_State when System stops for high temperature detection
744-934 U4_2_FSR_CTL_STATE_OLD 0 0~99 FSR_State immediately before System stops for high temperature detection
744-935 U4_2_FSR_FS1_TMP 0 0~99 FS1_Tem when System stops for high temperature detection
744-935 U4_2_FSR_FS1_TMP 0 0~99
