Xerox WorkCentre 5225 Service Manual

February, 2008
6-14
WorkCentre 5225, 5230
IOT NVM List
Launch Version
General Procedures
Chain 749-xxx ROS
744-936 U4_2_FSR_FS1_TMP_OLD1 0 0~99 FS1_Temp1 immediately before System stops for high temperature detection
744-936 U4_2_FSR_FS1_TMP_OLD1 0 0~99
744-937 U4_2_FSR_FS1_TMP_OLD2 0 0~99 FS1_Temp2 immediately before System stops for high temperature detection
744-937 U4_2_FSR_FS1_TMP_OLD2 0 0~99
744-938 U4_2_FSR_FS1_TMP_OLD3 0 0~99 FS1_Temp3 immediately before System stops for high temperature detection
744-938 U4_2_FSR_FS1_TMP_OLD3 0 0~99
744-939 U4_2_FSR_FS2_TMP 0 0~99 FS2_Tem when System stops for high temperature detection
744-939 U4_2_FSR_FS2_TMP 0 0~99
744-940 U4_2_FSR_FS2_TMP_OLD1 0 0~99 FS2_Temp1 immediately before System stops for high temperature detection
744-940 U4_2_FSR_FS2_TMP_OLD1 0 0~99
744-941 U4_2_FSR_FS2_TMP_OLD2 0 0~99 FS2_Temp2 immediately before System stops for high temperature detection
744-941 U4_2_FSR_FS2_TMP_OLD2 0 0~99
744-942 U4_2_FSR_FS2_TMP_OLD3 0 0~99 FS2_Temp3 immediately before System stops for high temperature detection
744-942 U4_2_FSR_FS2_TMP_OLD3 0 0~99
Table 8 FUSER
Chain-
Link Name Default Range 1 Count Remarks
Table 9 ROS
Chain-
Link
Name Default Range 1 Count Remarks
749-001 ALL TRAY-LASER SIDE REGI ADJUSTMENT 50 1~99 0.254mm Not available
749-002 TRAY1-LASER SIDE REGI ADJUSTMENT 50 1~99 0.254mm Not available
749-003 TRAY2-LASER SIDE REGI ADJUSTMENT 50 1~99 0.254mm Not available
749-004 TRAY3-LASER SIDE REGI ADJUSTMENT 50 1~99 0.254mm Not available
749-005 TRAY4-LASER SIDE REGI ADJUSTMENT 50 1~99 0.254mm Not available
749-006 HCF-LASER SIDE REGI ADJUSTMENT 50 1~99 0.254mm Not available
749-007 MSI-LASER SIDE REGI ADJUSTMENT 50 1~99 0.254mm Not available
749-009 DUP ALL TRAY-LASER SIDE REGI ADJUSTMENT 50 1~99 0.254mm Not available
749-010 DUP TRAY1-LASER SIDE REGI ADJUSTMENT 50 1~99 0.254mm Not available
749-011 DUP TRAY2-LASER SIDE REGI ADJUSTMENT 50 1~99 0.254mm Not available
749-012 DUP TRAY3-LASER SIDE REGI ADJUSTMENT 50 1~99 0.254mm Not available
749-013 DUP TRAY4-LASER SIDE REGI ADJUSTMENT 50 1~99 0.254mm Not available
749-014 DUP HCF-LASER SIDE REGI ADJUSTMENT 50 1~99 0.254mm Not available
749-015 DUP MSI-LASER SIDE REGI ADJUSTMENT 50 1~99 0.254mm Not available
749-505 ROS Beam Position LD2 10 0~20 1 Not available
749-516 IMAGE AREA 0 0~1 - 0: NORMAL IMAGE AREA 1: WIDE IMAGE AREA
749-522 END ERASE OFFSET VALUE ADJUSTMENT 50 0~99 0.363mm Not available
749-523 SIDE NORMAL ERASE ADJUSTMENT 8 0~16 0.254mm Nominal=2.032mm
749-524 TOP NORMAL ERASE ADJUSTMENT 9 0~18 0.217mm Nominal=1.953mm
749-527 END NORMAL ERASE ADJUSTMENT 9 0~18 0.217mm Nominal=1.953mm
