Xerox WorkCentre 5225 Service Manual

February, 2008
6-16
WorkCentre 5225, 5230
IOT NVM List
Launch Version
General Procedures
Chain 740-xxx Chain 749-xxx Chain-751-xxx XERO
752-893 First 2Digits of Manual Light Volume Adjustment
LDman
50 47~52 1 Not available
752-893 Last 2Digits of Manual Light Volume Adjustment
LDman
00 00~99 1
752-954 ATC Sensor 0 0~1 1 ATC Sensor 0: Normal, 1: Abnormal
752-955 First 2Digits of Delta ATCman 50 49~50 1 ATC manual correction (higher digits)
752-955 Last 2Digits of Delta ATCman 0 0~99 1 ATC manual correction (lower digits)
753-001 Toner Empty (for CRUM Read) 0 0~1 1 Not available
753-004 ATC OUT Last 2Digits (for CRUM Read) 70 00~255 1 Not available
753-005 ATC OUT First 2Digits (for CRUM Read) 3 00~255 1 Not available
753-006 ATC Sensor (for CRUM Read) 0 0~1 - For reading 42-3 data stored in the CRUM.
753-007 CRU New or Old (for CRUM Read) 0 0~1 - For reading 49-63 (0: New/1: Old) data stored in the CRUM.
753-008 First 2Digits of CRU ATC S 3 0~10 1
Not available
753-008 Last 2Digits of CRU ATC S 80 0~99 1
753-009 Exchange DRUM in No CRUM Country 0 0~1 1 Not available
753-612 Toner Refill Rate [mg/s] 22 0~254 1 Not available
753-619 Toner Empty Status 0 0~4 1 Not available
753-645 PreNear Threshold Value (Threshold Value of
Remaining Toner [%])
114 0~254 1 Not available
753-673 Remaining Toner [%] - 0~200 1 Not available
753-705 Flag indicating CRU Layer Formation Complete 0 0~1 1 Not available
753-716 ATC Code (ATC Sensor Properties) 55 0~99 1 Not available
753-725 Last 2Digits of ICDC Accumulative Value since
Empty until TC Lower Limit
0 0~99 1 Not available
753-726 First 2Digits of ICDC Accumulative Value since
Empty until TC Lower Limit
0 0~99 1 Not available
753-731 PR_VL 87 30~150 1 Not available
753-737 Toner Empty Status (for CRUM Read) 0 0~255 1 Not available
753-742 ATC Code (ATC Sensor Properties) (for CRUM
Read)
55 0~255 1 Not available
Table 10 Procon
Chain-
Link Name Default Range 1 Count Remarks
Table 11 XERO
Chain-
Link
Name Default Range 1 Count Remarks
740-560 Print Volume Setting for Forced Drum Reverse 0 0~10 50 sheets
749-016 Pre-Exposure Control 0 0~254 1 kHz 0: Off (Always) 254: On (Always) 1~253: On (Drum Cycle mode change) For 1~253 pre-
exposure (Drum Cycle mode change), 1 count is equivalent to 1 Kcycle. The recom
-
mended value is 122 (Kcycle).
