February, 2008
6-18
WorkCentre 5225, 5230
IOT NVM List
Launch Version
General Procedures
Chain 751-xxx CRU
751-890 BCR Iac Output A UNDER (for LL)
(Temperature is 28deg.C or more. The number of
drum cycles is less than the threshold value.)
0 0~100 1% Valid when BCR Iac control change is On (the value is 1). Min (0): 1.30 mA, Max (100):
1.6 mA, init (0): 1.3 mA
751-891 BCR Iac Output A OVER (for LL)
(Temperature is 28deg.C or more. The number of
drum cycles is more than or equal to the threshold
value.)
0 0~100 1% Valid when BCR Iac control change is On (the value is 1). Min (0): 1.30 mA, Max (100):
1.6 mA, init (0): 1.3 mA
Table 11 XERO
Chain-
Link Name Default Range 1 Count Remarks
Table 12 CRU
Chain-
Link
Name Default Range 1 Count Remarks
751-001 Drum Rotation Time(Cycle Count), 1st & 2nd digits 0 0~255 1
751-001 Drum Rotation Time(Cycle Count), 3rd & 4th digits 0 0~255 1
751-001 Drum Rotation Time(Cycle Count), 5th & 6th digits 0 0~255 1
751-001 Drum Rotation Time(Cycle Count), 7th & 8th digits 0 0~255 1
751-003 Return Normal CRU MODE 0 0~1 - Return to Normal CRU MODE
751-009 Drum Life Pre Warning Detection Cycle 40 1~254 0.5 kHz Sets the timing (the number of Drum cycles until Drum Life End) to display a Pre-Warn-
ing. (Initial value= 20.0 kHz.) (Only a value that is larger than the value for Drum Life
Warning can be entered.)
751-010 Drum Life Warning Detection Cycle 12 1~254 0.5 kHz Sets the timing (the number of Drum cycles until Drum Life End) to display a Warning.
(Initial value = 6.0 kHz.) (Only a value that is smaller than the value for Drum Life Pre-
Warning can be entered.)
751-041 Toner Disp Time 0 - 0~255 - TONER: Dispense motor driving time (the 0th byte)
751-041 Toner Disp Time 1 - 0~255 - TONER: Dispense motor driving time (the 1st byte)
751-041 Toner Disp Time 2 - 0~255 - TONER: Dispense motor driving time (the 2nd byte)
751-041 Toner Disp Time 3 - 0~255 - TONER: Dispense motor driving time (the 3rd byte)
751-042 Toner Filling 0 - 0~255 - TONER: The amount of toner supplied from the toner bottle (the 0th byte)
751-043 Toner Filling 1 - 0~255 - TONER: The amount of toner supplied from the toner bottle (the 1st byte)
751-044 Toner Capacity - 0~255 - TONER: The capacity of the toner bottle
751-089 Drum Life Pre Warning Detection Cycle (for LL) 40 1~254 0.5 kHz Sets the timing (the number of Drum cycles until Drum Life End) to display a Pre-Warn-
ing. (Initial value= 20.0 kHz.) (Only a value that is larger than the value for Drum Life
Warning can be entered.)
751-090 Drum Life Warning Detection Cycle (for LL) 12 1~254 0.5 kHz Sets the timing (the number of Drum cycles until Drum Life End) to display a Warning.
(Initial value = 6.0 kHz.) (Only a value that is smaller than the value for Drum Life Pre-
Warning can be entered.)
751-503 Custom Mode 0 0~2 Sets the accuracy of the Drum/Toner life misdetection prevention function.
0: Custom Mode normal
1: Invalid (operates as in custom mode normal)
2: Custom Mode A (Toner can be refilled)
To Next Page
