February, 2008
6-19
WorkCentre 5225, 5230
IOT NVM List
General Procedures
Launch Version
Chain 763-xxx SB Finisher
Table 13 SB Finisher
Chain-link Name Default Range 1 Count Remarks
763-600 Ex_Finisher_Major_Version - 1, 2 Digit - 0~99 Finisher Software Major Version.
763-600 Ex_Finisher_Major_Version - 3, 4 Digit - 0~99
763-600 Ex_Finisher_Major_Version - 5, 6 Digit - 0~6
763-601 Ex_Finisher_Minor_Version - 1, 2 Digit - 0~99 Finisher Software Minor Version.
763-601 Ex_Finisher_Minor_Version - 3, 4 Digit - 0~99
763-601 Ex_Finisher_Minor_Version - 5, 6 Digit - 0~6
763-602 Ex_Finisher_Local_Version - 0~255 Finisher Software Local Version.
763-603 Ex_Finisher_Patch_Version - 1, 2 Digit - 0~99 Finisher Software Patch Version.
763-603 Ex_Finisher_Patch_Version - 3, 4 Digit - 0~99
763-603 Ex_Finisher_Patch_Version - 5, 6 Digit - 0~6
763-605 NVM_Puncher_Type 0 0~6 Type of Puncher installed.
0: None, 1: 2 holes, 2: 3 holes, 3: 2/3 holes, 5: 2/4 holes, 6: Swd 4 holes.
763-608 NVM_Buffer_Request 0 0~1 Buffer operation request. 0: Request, 1: Do not request.
763-610 NVM_Add_Pitch_Sheet 0 0~255 Maximum volume of stapled paper that can be compiled.
763-611 NVM_Add_Pitch_Set 0 0~255 Maximum volume of small-sized and Unstapled paper that can be compiled.
763-613 Diag_Fault_Clear_Check_Enble 0 0~1 Static jam detection in diagnostic mode.
0: FaultClear is detected in diagnostic mode.
1: FaultClear is not detected in diagnostic mode.
763-616 NVM_S_Stpl_Full_Stack_Pos_Encoder_S_Size 63 1~135 Full stack positional Encoder limitation during single staple mode or single staple/unsta-
ple mode for small size paper (paper length = or < 216 mm).
763-617 NVM_S_Stpl_Full_Stack_Pos_Encoder_L_Size 50 1~135 Full stack positional Encoder limitation during single staple mode or single staple/unsta-
ple mode for large size paper (paper length > 216 mm).
763-618 NVM_D_Stpl_Full_Stack_Pos_Encoder_S_Size 50 1~135 Full stack positional Encoder limitation during dual staple mode or single staple/unsta-
ple/dual staple mode for small size paper (paper length = or < 216 mm).
763-619 NVM_D_Stpl_Full_Stack_Pos_Encoder_L_Size 50 1~135 Full stack positional Encoder limitation during dual staple mode or single staple/unsta-
ple/dual staple mode for large size paper (paper length > 216 mm).
763-620 NVM_Unstpl_Full_Stack_Pos_Encoder_S_Size 116 1~135 Full stack positional Encoder limitation during unstaple mode for small size paper
(paper length = or < 216 mm).
763-621 NVM_Unstpl_Full_Stack_Pos_Encoder_L_Size 63 1~135 Full stack positional Encoder limitation during unstaple mode for small size paper
(paper length > 216 mm).
763-622 NVM_Full_Stack_Pos_Encoder_Limit 26 1~28 Mix full stack positional Encoder limitation.
763-623 NVM_Mixsize_Full_Check_Enable 1 0~1 Mix size stack after mix stack position is detected.
0: Not prohibited, 1: Prohibited
763-624 Ex_Max_Compile_Sheet_Count_For_Unstaple_Sm
all
5 2~50 Number of sheets of small-sized paper in an ejected unstapled set.
763-625 Ex_Max_Compile_Sheet_Count_For_Unstaple_Big 25 2~50 Number of sheets of large-sized paper in an ejected unstapled set.
763-626 NVM_Staple_Stack_Set_Limit_S_Size 100 1~255 Maximum number of copies of small-sized paper allowed in the Stacker in single staple
mode or unstaple and single staple mode.
763-627 NVM_Large_Staple_Stack_Set_Limit_L_Size 75 1~255 Full stack positional Encoder limitation during unstaple mode for large size paper (paper
length > 216 mm).
