Xerox WorkCentre 5225 Service Manual

February, 2008
6-26
WorkCentre 5225, 5230
IOT NVM List
Launch Version
General Procedures
763-744 NVM_Book_Eject_Exit_Speed_Less_L 4 1~4 When outputting large-size (paper length > 330 mm) booklets, the exit speed of the
Eject Motor is set as follows:
1 = low speed, 2 = middle speed, 3 = high speed, 4 = super high speed.
763-745 NVM_Book_Eject_Exit_Speed_More_L 4 1~4 When outputting large-size (paper length > 330 mm) booklets, if the Eject Motor speed
switch count is more than the set value (NVM 763-743), the exit speed of the Eject
Motor is set as follows:
1 = low speed, 2 = middle speed, 3 = high speed, 4 = super high speed.
763-746 NVM_Book_Sub_Pdl_Sol_Times 1 1~5 The Sub Paddle Sol On operating frequency is set at Booklet Job.
763-747 NVM_Book_Transport_Select 4 1~6 Sets the transport speed from the Eject Motor to the booklet staple position. Also cor-
rects the timing for the Set Clamp Goback operation.
1: 1617 pps (403.0 mm/sec.), 2: 400 pps (99.7 mm/sec.), 3: 645 pps (160.7 mm/sec.),
4: 839 pps (209.1 mm/sec.), 5: 1034 pps (257.7 mm/sec.), 6: 1210 pps (301.5 mm/
sec.).
763-748 NVM_Book_Tray_Up2 12 0~40 Sets the limit of upward travel for the first time the Tray goes up after the Booklet Staple
Job. Default is “[NVM 763-731] - [NVM 763-732]”.
763-749 NVM_Fold_Tray_Down_Sheet_Count 12 1~50 In Fold Job mode (Booklet UnStaple Job, BiFold Job), the number of sheets which
causes the Output Tray to move down 1 increment.
763-750 NVM_Stk_Eject_Unstpl_Exit_Speed_1 6 1~6 Exit speed of the Eject Motor for small size paper (paper length < Letter L) for sheets 1-
3 of the set during Stacker unstaple job mode.
1: 160.7 mm/sec., 2: 209.1 mm/sec., 3: 257.7 mm/sec., 4: 301.5 mm/sec., 5: 353.9 mm/
sec., 6: 403.0 mm/sec.
763-751 NVM_Stk_Eject_Unstpl_Exit_Speed_2 5 1~6 Exit speed of the Eject Motor for small size paper (paper length < Letter L) for sheets 4-
6 of the set during Stacker unstaple job mode.
1: 160.7 mm/sec., 2: 209.1 mm/sec., 3: 257.7 mm/sec., 4: 301.5 mm/sec., 5: 353.9 mm/
sec., 6: 403.0 mm/sec.
763-752 NVM_Stk_Eject_Unstpl_Exit_Speed_3 3 1~6 Exit speed of the Eject Motor for small size paper (paper length < Letter L) for sheets 7
and above of the set during Stacker unstaple job mode.
1: 160.7 mm/sec., 2: 209.1 mm/sec., 3: 257.7 mm/sec., 4: 301.5 mm/sec., 5: 353.9 mm/
sec., 6: 403.0 mm/sec.
763-753 NVM_Stk_Eject_Unstpl_Exit_Speed_L 6 1~6 Exit speed of the Eject Motor for large size paper (paper length > Letter L) during
Stacker unstaple job mode.
1: 160.7 mm/sec., 2: 209.1 mm/sec., 3: 257.7 mm/sec., 4: 301.5 mm/sec., 5: 353.9 mm/
sec., 6: 403.0 mm/sec.
763-755 NVM_Stk_Eject_Stpl_Exit_Speed_L 6 1~6 Exit speed of the Eject Motor for large size paper (paper length = or > 13 inches) during
front/rear staple job mode.
1: 160.7 mm/sec., 2: 209.1 mm/sec., 3: 257.7 mm/sec., 4: 301.5 mm/sec., 5: 353.9 mm/
sec., 6: 403.0 mm/sec.
763-756 NVM_Book_Traydown_Setcount_S1 4 1~15 The number of increments the Tray moves down after a booklet staple set is outputted.
Small size: Each increment ~ 3 copies.
763-757 NVM_Book_Traydown_Setcount_S2 5 1~15 The number of increments the Tray moves down after a booklet staple set is outputted.
Small size: Each increment 4 ~ 7 copies.
763-758 NVM_Book_Traydown_Setcount_S3 3 1~15 The number of increments the Tray moves down after a booklet staple set is outputted.
Small size: Each increment 8 ~ 10 copies.
763-759 NVM_Book_Traydown_Setcount_S4 1 1~15 The number of increments the Tray moves down after a booklet staple set is outputted.
Small size: Each increment 11 ~ copies.
Table 13 SB Finisher
Chain-link Name Default Range 1 Count Remarks
