Xerox WorkCentre 5225 Service Manual

February, 2008
6-28
WorkCentre 5225, 5230
IOT NVM List
Launch Version
General Procedures
763-781 NVM_Stk_Eject_Stpl_Exit_Speed_M2 6 1~6 Exit speed of the Eject Motor for medium size paper (paper length > Letter L~13 inches)
for sheets 10-29 during front/rear staple job mode.
1: 160.7 mm/sec., 2: 209.1 mm/sec., 3: 257.7 mm/sec., 4: 301.5 mm/sec., 5: 353.9 mm/
sec., 6: 403.0 mm/sec.
763-782 NVM_Stk_Eject_Stpl_Exit_Speed_M3 6 1~6 Exit speed of the Eject Motor for medium size paper (paper length > Letter L~13 inches)
for sheets 30 and above during front/rear staple job mode.
1: 160.7 mm/sec., 2: 209.1 mm/sec., 3: 257.7 mm/sec., 4: 301.5 mm/sec., 5: 353.9 mm/
sec., 6: 403.0 mm/sec.
763-783 NVM_Stk_Eject_Dual_Stpl_Exit_Speed_S1 5 1~6 Exit speed of the Eject Motor for small size paper (paper length < Letter L) for sheets 1-
9 during dual staple job mode.
1: 160.7 mm/sec., 2: 209.1 mm/sec., 3: 257.7 mm/sec., 4: 301.5 mm/sec., 5: 353.9 mm/
sec., 6: 403.0 mm/sec.
763-784 NVM_Stk_Eject_Dual_Stpl_Exit_Speed_S2 3 1~6 Exit speed of the Eject Motor for small size paper (paper length < Letter L) for sheets
10-29 during dual staple job mode.
1: 160.7 mm/sec., 2: 209.1 mm/sec., 3: 257.7 mm/sec., 4: 301.5 mm/sec., 5: 353.9 mm/
sec., 6: 403.0 mm/sec.
763-785 NVM_Stk_Eject_Dual_Stpl_Exit_Speed_S3 3 1~6 Exit speed of the Eject Motor for small size paper (paper length < Letter L) for sheets 30
and above during dual staple job mode.
1: 160.7 mm/sec., 2: 209.1 mm/sec., 3: 257.7 mm/sec., 4: 301.5 mm/sec., 5: 353.9 mm/
sec., 6: 403.0 mm/sec.
763-786 NVM_Stk_Eject_Dual_Stpl_Exit_Speed_M1 6 1~6 Exit speed of the Eject Motor for medium size paper (paper length > Letter L~13 inches)
for sheets 1-9 during dual staple job mode.
1: 160.7 mm/sec., 2: 209.1 mm/sec., 3: 257.7 mm/sec., 4: 301.5 mm/sec., 5: 353.9 mm/
sec., 6: 403.0 mm/sec.
763-787 Ex_Booklet_Fold_Count_Lower - 1, 2 Digit 0 0~99 Booklet fold frequency (lower value).
Total fold frequency = (upper value) x 65536 + (lower value).
763-787 Ex_Booklet_Fold_Count_Lower - 3, 4 Digit 0 0~99
763-787 Ex_Booklet_Fold_Count_Lower - 5, 6 Digit 0 0~6
763-788 Ex_Booklet_Fold_Count_Upper - 1, 2 Digit 0 0~99 Booklet fold frequency (upper value).
Total fold frequency = (upper value) x 65536 + (lower value).
763-788 Ex_Booklet_Fold_Count_Upper - 3, 4 Digit 0 0~99
763-788 Ex_Booklet_Fold_Count_Upper - 5, 6 Digit 0 0~6
763-789 Ex_Total_Booklet_Stapling_Counter_Lower - 1, 2
Digit
0 0~99 Booklet staple operation frequency (lower value).
Total staple frequency = (upper value) x 65536 + (lower value).
763-789 Ex_Total_Booklet_Stapling_Counter_Lower - 3, 4
Digit
0 0~99
763-789 Ex_Total_Booklet_Stapling_Counter_Lower - 5, 6
Digit
0 0~6
763-790 Ex_Total_Booklet_Stapling_Counter_Upper - 1, 2
Digit
0 0~99 Booklet staple operation frequency (upper value).
Total staple frequency = (upper value) x 65536 + (lower value).
763-790 Ex_Total_Booklet_Stapling_Counter_Upper - 3, 4
Digit
0 0~99
763-790 Ex_Total_Booklet_Stapling_Counter_Upper - 5, 6
Digit
0 0~6
Table 13 SB Finisher
Chain-link Name Default Range 1 Count Remarks
