Xerox WorkCentre 5225

February, 2008
6-56
WorkCentre 5225, 5230
Launch Version
General Procedures
711-032 DADF Tail Edge Fine Adjustment (Side1)
(75.0mm/sec.)
129 0~255 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -5.8mm (+126 pulse) Tail Edge
adjustment = Lead Registration adjustment value + Tail Edge fine adjustment value
711-033 DADF Tail Edge Fine Adjustment (Side1)
(100.0mm/sec.)
129 0~255 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -5.8mm (+126 pulse) Tail Edge
adjustment = Lead Registration adjustment value + Tail Edge fine adjustment value
711-034 DADF Tail Edge Fine Adjustment (Side1)
(133.3mm/sec.)
129 0~255 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -5.8mm (+126 pulse) Tail Edge
adjustment = Lead Registration adjustment value + Tail Edge fine adjustment value
711-035 DADF Tail Edge Fine Adjustment (Side1)
(150.0mm/sec.)
129 0~255 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -5.8mm (+126 pulse) Tail Edge
adjustment = Lead Registration adjustment value + Tail Edge fine adjustment value
711-036 DADF Tail Edge Fine Adjustment (Side1)
(200.0mm/sec.)
129 0~255 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -5.8mm (+126 pulse) Tail Edge
adjustment = Lead Registration adjustment value + Tail Edge fine adjustment value
711-037 DADF Tail Edge Fine Adjustment (Side1)
(300.0mm/sec.)
129 0~255 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -5.8mm (+126 pulse) Tail Edge
adjustment = Lead Registration adjustment value + Tail Edge fine adjustment value
711-043 DADF Tail Edge Fine Adjustment (Side2)
(37.5mm/sec.)
129 0~255 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -5.8mm (+126 pulse) Tail Edge
adjustment = Lead Registration adjustment value + Tail Edge fine adjustment value
711-044 DADF Tail Edge Fine Adjustment (Side2)
(50.0mm/sec.)
129 0~255 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -5.8mm (+126 pulse) Tail Edge
adjustment = Lead Registration adjustment value + Tail Edge fine adjustment value
711-045 DADF Tail Edge Fine Adjustment (Side2)
(66.7mm/sec.)
129 0~255 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -5.8mm (+126 pulse) Tail Edge
adjustment = Lead Registration adjustment value + Tail Edge fine adjustment value
711-046 DADF Tail Edge Fine Adjustment (Side2)
(75.0mm/sec.)
129 0~255 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -5.8mm (+126 pulse) Tail Edge
adjustment = Lead Registration adjustment value + Tail Edge fine adjustment value
711-047 DADF Tail Edge Fine Adjustment (Side2)
(100.0mm/sec.)
129 0~255 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -5.8mm (+126 pulse) Tail Edge
adjustment = Lead Registration adjustment value + Tail Edge fine adjustment value
711-048 DADF Tail Edge Fine Adjustment (Side2)
(133.3mm/sec.)
129 0~255 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -5.8mm (+126 pulse) Tail Edge
adjustment = Lead Registration adjustment value + Tail Edge fine adjustment value
711-049 DADF Tail Edge Fine Adjustment (Side2)
(150.0mm/sec.)
129 0~255 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -5.8mm (+126 pulse) Tail Edge
adjustment = Lead Registration adjustment value + Tail Edge fine adjustment value
711-050 DADF Tail Edge Fine Adjustment (Side2)
(200.0mm/sec.)
129 0~255 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -5.8mm (+126 pulse) Tail Edge
adjustment = Lead Registration adjustment value + Tail Edge fine adjustment value
711-051 DADF Tail Edge Fine Adjustment (Side2)
(300.0mm/sec.)
129 0~255 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -5.8mm (+126 pulse) Tail Edge
adjustment = Lead Registration adjustment value + Tail Edge fine adjustment value
711-057 Vertical Ratio Fine Adjustment (37.5mm/sec.) 20 0~40 0.001 Initial value 0% (20) +/-2% (+/-20), 0.1% increments Adjusts only Top Speed for Feed
Motor and Regi Motor.
711-058 Vertical Ratio Fine Adjustment (50.0mm/sec.) 20 0~40 0.001 Initial value 0% (20) +/-2% (+/-20), 0.1% increments Adjusts only Top Speed for Feed
Motor and Regi Motor.
711-059 Vertical Ratio Fine Adjustment (66.7mm/sec.) 20 0~40 0.001 Initial value 0% (20) +/-2% (+/-20), 0.1% increments Adjusts only Top Speed for Feed
Motor and Regi Motor.
711-060 Vertical Ratio Fine Adjustment (75.0mm/sec.) 20 0~40 0.001 Initial value 0% (20) +/-2% (+/-20), 0.1% increments Adjusts only Top Speed for Feed
Motor and Regi Motor.
711-061 Vertical Ratio Fine Adjustment (100.0mm/sec.) 20 0~40 0.001 Initial value 0% (20) +/-2% (+/-20), 0.1% increments Adjusts only Top Speed for Feed
Motor and Regi Motor.
711-062 Vertical Ratio Fine Adjustment (133.3mm/sec.) 20 0~40 0.001 Initial value 0% (20) +/-2% (+/-20), 0.1% increments Adjusts only Top Speed for Feed
Motor and Regi Motor.
711-063 Vertical Ratio Fine Adjustment (150.0mm/sec.) 20 0~40 0.001 Initial value 0% (20) +/-2% (+/-20), 0.1% increments Adjusts only Top Speed for Feed
Motor and Regi Motor.
Table 2 CVT DADF NVM LIST
Chain-Link Content Default Range 1 Count Meaning
