February, 2008
2-56
WorkCentre 5225, 5230
005-122
Launch Version
Status Indicator Raps
005-122 CVT Simplex/Side1 Pre-Registration On JAM RAP
After the Pre Feed operation started for the first sheet (DADF Feed Motor On (CW)) in
Duplex or Simplex mode, the Pre-Registration Sensor did not turn On within the specified
time.
After the Pre Feed operation started for the second sheet onwards (DADF Feed Motor On
(CW)) in Duplex mode, the Pre-Registration Sensor did not turn On within the specified
time.
Initial Actions
Refer to BSD 5.4/5.5.
Procedure
Execute Component Control[005-206]. Actuate the DADF Pre Registration Sensor (PL 15.7)
with paper.
The display changes.
YN
Check the connections of P/J781 and P/J761. P/J781 and P/J761 are connected cor-
rectly.
YN
Connect P/J781 and P/J761.
Check the wire between J781 and J761 for an open circuit or a short circuit (BSD 5.4 Flag
3/Flag 4).
The wire between J781 and J761 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the DADF PWB P761-10 (+) and GND (-) (BSD 5.4 Flag
4).
The voltage is approx. +5VDC.
YN
Replace the DADF PWB (PL 15.3).
Measure the voltage between the DADF PWB P761-12 (+) and GND (-) (BSD 5.4 Flag 3).
Actuate the DADF Pre Registration Sensor with paper. The voltage changes.
YN
Replace the DADF Pre Registration Sensor (PL 15.7).
Replace the DADF PWB (PL 15.3).
Execute Component Control[005-001]. The DADF Feed Motor (PL 15.9) starts up.
YN
Check the connections of P/J764 and P/J754. P/J764 and P/J754 are connected cor-
rectly.
YN
Connect P/J764 and P/J754.
Check the wire between J764 and J754 for an open circuit or a short circuit (BSD 5.5 Flag
1).
The wire between J764 and J754 is conducting without an open circuit or a short
circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the DADF PWB (PL 15.3) P754-1 (+) and GND (-), and
between P754-7 (+) and GND (-) (BSD 5.5 Flag 1).
The voltage is approx. +24VDC.
YN
Replace the DADF PWB (PL 15.3).
Replace the DADF Feed Motor (PL 15.9). If the problem persists, replace the DADF PWB
(PL 15.3).
Replace the DADF PWB (PL 15.3).
A
A
B
B
