Yamaha F115A - Page 228

5-17
POWR
E
ECM AND JUNCTION BOX ASSEMBLY
5
4
Order Job/Part Q’ty Remarks
21 Idle speed control valve coupler 1
22 Fuel injectors coupler 4
23 High-pressure fuel pump coupler 1
24 Shift position switch coupler 1
25 Plastic locking tie 1
26 Plastic locking tie 1
27 Connector 1
28 Oil pressure switch coupler 1
For installation, reverse the removal
procedure.
14
A
A
B
B
19
20
23
22
21
25
24
26
2
5
4
8
4
9
7
3
6
12
10
13
16
15
28
27
17
6 × 28 mm
18
6 × 16 mm
6 × 16 mm
6 × 25 mm
6 × 28 mm
6 × 16 mm
6 × 12 mm
11
1
5200
Not reusable
Not reusable
