Appendix
12 - 6
12.3 Peripheral Device Application Precautions
J
Selecting and Installing Molded-case Circuit Breaker (MCCB)
Install a molded-case circuit breaker (MCCB) on the power supply line to the Inverter to protect the wiring.
SelecttheMCCBaccordingto theInverter’spowersupplypowerfactor(whichchangeswiththesupplyvolt-
age, output frequency, and load) . Contact your Yaskawa representative for selection standards. Operating
characteristics of completely magnetic MCCBs change with high-frequency currents. Select a model with
a large capacity. We recommend using only ground fault interrupters designed for inverters.
J
Using Magnetic Contactors on the Power Supply Line
TheInvertercan beusedwithout amagneticcontactor onthepower supplyline.Althoughamagneticcontac-
tor can be installed to protect from accidents that can occur by automatic recovery following power losses
during remote operation, do not start and stop operation frequently with a magnetic contactor installed on
the power supply line. Doing so can cause the Inverter to malfunction. The motor will not be automatically
restartedafter powerrecovery duringDigital Operatoroperation,andstartingviaamagneticcontactoristhus
not possible.
Althoughoperationcanbestoppedusingamagneticcontactor inthepower supplyline,the regenerativecon-
trol of the Inverter will not operate and a coast to a stop will occur. If a Braking Unit or Braking Resistor Unit
isused,wireasequencethat turns OFFthemagneticcontactorwiththe thermal protectorcontactoftheBrak-
ing Resistor Unit.
J
Using Magnetic Contactors on the Motor Line
As a rule, so not install a magnetic contactor between the Inverter and motor to turn the motor ON and OFF
during operation. Supplying power to the motor while the Inverter is operating will cause a large surge cur-
rent to flow, and the Inverter’s overcurrent protection function will operate. If a magnetic contactor is
installed to switch to a commercial power supply, switch the lines only after stopping both the Inverter and
the motor. Use the speed search function is switching is required while the motor shaft is rotating.
If a magnetic contactor is required for momentary power losses, use a contactor with delayed operation.
J
Installing Thermal Overload Relays
The Inverter has a protection function using an electronic thermal to protect the motor from overheating.
However, if more than one motor is operated from one Inverter or if a multi-pole motor is operated, install
thermal overload relays or thermal protectors between the Inverter and motors. Set the constant L1-01 to “0”
and set the heat-operating thermal overload relay or thermal protector to 1.0 times the value on the motor
nameplate at 50 Hz or 1.1 times the value at 60 Hz.
J
Improving the Power Factor (Eliminating Phase Advancing Capacitors)
Install a DC or AC reactor on the power supply line to the Inverter to improve the power factor. (200 V class
Inverters of 18.5 to 75kW and 400 V class Inverters of 18.5 to 160kW have built-in DC reactors.)
Capacitors or surgesuppressorson the output line from the Inverter can overheat or be destroyed by the high-
frequency component ofthe Inverter’s output. They can also cause overcurrents to flow to the Inverter,caus-
ingtheovercurrentprotectionfunctiontoactivate. Donotinstall capacitorsorsurgesuppressorsintheoutput
line.
J
Electromagnetic Interference
The Inverter’s I/O circuits (main circuits) contain a high-frequency component, which may adversely affect
communications devices (e.g., AM radios) located nearby. This interference can be reduced by installing
noise filters, or you can install the wiring between the Inverter and motor and the power supply wiring in a
metal duct and ground the duct.
12
