4.2 Modes
4-9
A
EXAMPLE
"
Setting a User Constant in the Basic Access Level
The function level will be displayed when the DATA/ENTER Key is pressed at the programming mode
display.
Use the following display to set the acceleration time to 20.0 s.
Step Key Sequence Digital Operator Display Remarks
1
MENU
G5: Main Menu :
Operation
2
Press twice.
G5: Main Menu :
Programming
3
DATA
ENTER
Function b1
Sequence
Changed to constant reading (func-
tion) level.
4
Function b2
DC Braking
5
Function C1
Accel/Decel
6
DATA
ENTER
Accel Time 1
C1−01 = 10.0 Sec
Changed to constant setting level,.
7
DATA
ENTER
Accel Time 1
0010.0 Sec
Selects the user constant so that the
leading 0 blinks. The blinking digit
can be changed.
8
RESET
Press twice.
Accel Time 1
0010.0 Sec
Blinking digit moves 2 places to the
right and the “1” blinks.
9
Accel Time 1
0020.0 Sec
Changes 1 to 2.
10
DATA
ENTER
Entry Accepted
Writes-in the new setting.
Accel Time 1
C1−01 = 20.0 Sec
The Operator display is as shown on
the left.
11
ESC
Function C1
Accel/Decel
Returns to “Function C1 Accel/Decel” display.
4
