YASKAWA CIMR-G5A Series User Manual

2-1
2
Handling Inverters
This chapter describes the checks required upon receiving a VS-616G5 In-
verter and describes installation methods.
2.1 Confirmations upon Delivery 2 - 2............
2.1.1 Nameplate Information 2 - 2.......................
2.2 Exterior and Mounting Dimensions 2 - 4.......
2.3 Checking and Controlling the
Installation Site 2 - 6.......................
2.3.1 Installation Site 2
-
6..............................
2.3.2 Controlling the Ambient Temperature 2 - 6...........
2.3.3 Protecting the Inverter from Foreign Matter 2
-
6......
2.4 Installation Orientation and Space 2 - 7.......
2.5 Removing/Attaching the Digital Operator
and Front Cover 2 - 8......................
2.5.1 Inverters of 15 kW or Less 2
-
8.....................
2.5.2 Inverters of 18.5 kW or Higher 2 - 9.................
2
