YASKAWA CIMR-G5A Series User Manual

6.3 V/f Control
6-23
V/f Patterns: 0.4 to 1.5 kW
D
Fixed Torque Characteristics (Settings 0 to 3)
Setting 0 50 Hz Setting 1 60 Hz Setting 2 60 Hz Setting 3 72 Hz
(V)
200
15
9
0 1.3 2.5 50 (Hz)
(V)
200
15
9
0 1.5 3 60 (Hz)
(V)
200
15
9
0 1.5 3 60 (Hz)
50
60
(Hz)
72
(V)
200
15
9
0 1.5 3
D
Variable Torque Characteristics (Settings 4 to 7)
Setting 4 50 Hz Setting 5 50 Hz Setting 6 60 Hz Setting 7 60 Hz
(V)
200
35
8
0 1.3 25 50 (Hz)
(V)
200
50
9
0 1.3 25 50 (Hz)
(V)
200
35
8
0 1.5 30 60 (Hz)
(V)
200
50
9
0 1.5 30 60 (Hz)
D
High Starting Torque Characteristics (Settings 8 to b)
Setting 8 50 Hz Setting 9 50 Hz Setting A 60 Hz Setting B 60 Hz
(V)
200
19
11
0 1.3 2.5 50 (Hz)
(V)
200
24
13
0 1.3 2.5 50 (Hz)
(V)
200
19
11
0 1.5 3 60 (Hz)
(V)
200
24
15
0 1.5 3 60 (Hz)
D
High-speed Operation (Settings C to E)
Setting C 90 Hz Setting D 120 Hz Setting E 180 Hz
(V)
200
15
9
0 1.5 3 60
(Hz)
90
(V)
200
15
9
0 1.5 3 60
(Hz)
120
(V)
200
15
9
0 1.5 3 60
(Hz)
180
The voltages above are for 200 V class Inverters. Double the voltages for 400 V class Inverters.
6
