YASKAWA CIMR-G5A Series User Manual

7-97
7.5.7 Operator Constants: o
J Operator Display Selection: o1-01 to o1-05
Constant Number Display Selection: o1-01
User
Change
during
Setting
Factory
Valid Access Levels
User
Constant
Number
Name
g
during
Opera-
tion
Setting
Range
Unit
Factory
Setting
V/f
Control
V/f with
PG
Open
Loop
Vector
Flux
Vector
o1-01
Constant No. display
selection
f
4to35 − 6
B B B B
D
In operation mode, the frequency reference, output frequency, output current, and output voltage can
be monitored immediately if the factory settings are being used. One of these four values, the output
voltage, can be changed to a different value.
D When you want to monitor a value other than the output voltage, set that number in constant o1-01.
D
Use the last two digits from the “U1 Monitor” list (U1-jj) to select a value. Refer to Table 4.3.
Monitor Selection After Power Up: o1-02
User
Change
during
Setting
Factory
Valid Access Levels
User
Constant
Number
Name
g
during
Opera-
tion
Setting
Range
Unit
Factory
Setting
V/f
Control
V/f with
PG
Open
Loop
Vector
Flux
Vector
o1-02
Monitor selection af-
ter power up
f 1to4 − 1
B B B B
D
When the power is turned on, the frequency reference will appear in the Unit’s data display if the facto-
ry settings are being used.
D
Any one of the four values monitored at startup (frequency reference, output frequency, output current,
or the value set in constant o1-01) can be selected to appear when the power is turned ON.
D
Change the setting of constant o1-02 to display an item other than the frequency reference at startup.
D
Settings
Setting Function
1
The frequency reference is displayed at start-up.
2
The output frequency is displayed at start-up.
3
The output current is displayed at start-up.
4
The value set in constant o1-01 is displayed at start-up.
Frequency Units of Reference Setting and Monitor: o1-03
D
Set the unit for frequency setting and monitoring.
User
Change
during
Setting
Factory
Valid Access Levels
User
Constant
Number
Name
g
during
Opera-
tion
Setting
Range
Unit
Factory
Setting
V/f
Control
V/f with
PG
Open
Loop
Vector
Flux
Vector
o1-03
Frequency units of
reference setting and
monitor
×
0 to 39999 − 0
B B B B
D
Settings
Setting Unit
0
0.01 Hz
1
0.01%
2to39
r/min (0 to 3999)
r/min = 120 × frequency reference (Hz) / o1-03 (number of motor poles)
40 to 39999
Use the 5th digit of o1-03 to specify the decimal point.
5th digit = 0: VVVV
5th digit = 1: VVV . V
5th digit = 2: VV . VV
5th digit = 3: V . VVV
The 1st to 4th digits of o1-03 determine the frequency setting
Ex 1: To set the 100% speed to 200.0, set o1-03 to 12000.
200.0 will be displayed for 100%, 120 will be displayed for 60%.
Ex 2: To set the 100% speed to 65.00, set o1-03 to 26500.
65.00 will be displayed for 100%, 39.00 will be displayed for 60%.
7
