YASKAWA CIMR-G5A Series User Manual

7-83
J
MEMOBUS Communications Settings: H5-01 to H5-05
Station Node Address: H5-01
D
Set the Inverter node address.
User
Change
during
Setting
Factory
Valid Access Levels
User
Constant
Number
Name
g
during
Opera-
tion
Setting
Range
Unit
Factory
Setting
V/f
Control
V/f with
PG
Open
Loop
Vector
Flux
Vector
H5-01
Station address
×
0to20 − 1F
A A A A
Baud Rate: H5-02
D
Set the baud rate for MEMOBUS communications.
User
Change
during
Setting
Factory
Valid Access Levels
User
Constant
Number
Name
g
during
Opera-
tion
Setting
Range
Unit
Factory
Setting
V/f
Control
V/f with
PG
Open
Loop
Vector
Flux
Vector
H5-02
Communication
speed selection
×
0to4 − 3
A A A A
D
Settings
Setting Baud Rate
0
1200 bps
1
2400 bps
2
4800 bps
3
9600 bps
4
19200 bps
Communication Parity: H5-03
D
Set the parity for MEMOBUS communications.
User
Change
during
Setting
Factory
Valid Access Levels
User
Constant
Number
Name
g
during
Opera-
tion
Setting
Range
Unit
Factory
Setting
V/f
Control
V/f with
PG
Open
Loop
Vector
Flux
Vector
H5-03
Communication par-
ity selection
×
0to2 − 0
A A A A
D
Settings
Setting Function
0
No parity
1
Even parity
2
Odd parity
Stopping Method after Communications Error: H5-04
D
Set the stopping method to used after a communications error is detected.
User
Change
during
Setting
Factory
Valid Access Levels
User
Constant
Number
Name
g
during
Opera-
tion
Setting
Range
Unit
Factory
Setting
V/f
Control
V/f with
PG
Open
Loop
Vector
Flux
Vector
H5-04
Stopping method af-
ter communication
error
×
0to3 − 3
A A A A
D
Settings
Setting Function
0
Deceleration to stop (deceleration time:C1-02)
1
Coast to stop
2
Emergency stop (deceleration time:C1-09)
3
Continue operation (display only)
