8.2 Programming Mode Constants
8-49
J
400 V Class Inverters
Con-
stant
Number
Name Unit Factory Setting
− Inverter Capacity kW 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11 15
18.5
o2-04 kVA selection --- 20 21 22 23 24 26 27 28 29
2A
C6-01 Carrier frequency upper limit
∗
1
kHz 15.0 15.0 15.0 15.0 15.0 15.0 12.5 12.5 10.0
10.0
−
Carrier frequency upper limit
range
kHz 15.0 15.0 15.0 15.0 15.0 15.0 15.0 15.0 15.0
15.0
C6-02 Carrier frequency lower limit
kHz 15.0 15.0 15.0 15.0 15.0 15.0 12.5 12.5 10.0
10.0
C6-03
Carrier frequency proportional
gain
--- 0 0 0 0 0 0 0 0 0
0
E2-01
(E5-01)
Motor rated current
A 1.00 1.60 3.10 4.20 7.00 9.80 13.30 19.9 26.5
32.9
E2-02
(E5-02)
Motor rated slip
Hz 2.90 2.60 2.50 3.00 2.70 1.50 1.30 1.70 1.60
1.67
E2-03
(E5-03)
Motor no-load current
A 0.60 0.80 1.40 1.50 2.30 2.60 4.00 5.6 7.6
7.8
E2-05
(E5-05)
Motor line-to-line resistance
Ω
38.198 22.459 10.100
6.495 3.333 1.595 1.152 0.922 0.550
0.403
E2-06
(E5-06)
Motor leak inductance
% 18.2 14.3 18.3 18.7 19.3 18.2 15.5 19.6 17.2
20.1
E2-10
Motor iron loss for torque com-
pensation
W 14 26 53 77 130 193 263 385 440
508
L2-02
Momentary power loss ridethru
time
sec 1.0 1.0 1.0 1.0 2.0 2.0 2.0 2.0 2.0
2.0
L2-03 Min. baseblock time
sec 0.5 0.5 0.5 0.5 0.5 0.7 0.7 0.7 0.7
0.7
L2-04 Voltage recovery time
sec 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3
0.3
Con-
stant
Number
Name Unit Factory Setting
− Inverter Capacity kW 22 30 37 45 55 75 110 160 185 220 300
o2-04 kVA selection 1 2B 2C 2D 2E 2F 30 32 34 35 36 37
C6-01 Carrier frequency upper limit
kHz 10.0 10.0 6.0 6.0 6.0 6.0 5.0 5.0 2.0 2.0 2.0
−
Carrier frequency upper limit
range
kHz 15.0 15.0 10.0 10.0 10.0 10.0 10.0 10.0 2.5 2.5 2.5
C6-02 Carrier frequency lower limit
kHz 10.0 10.0 6.0 6.0 6.0 6.0 5.0 5.0 2.0 2.0 2.0
C6-03
Carrier frequency proportional
gain
∗
2
--- 0 0 0 0 0 0 0 0 0 0 0
E2-01
(E5-01)
Motor rated current
A 38.6 52.3 65.6 79.7 95.0 130.0 190.0 270.0 310.0 370.0 500.0
E2-02
(E5-02)
Motor rated slip
Hz 1.70 1.80 1.33 1.60 1.46 1.39 1.40 1.35 1.30 1.30 1.25
E2-03
(E5-03)
Motor no-load current
A 9.2 10.9 19.1 22.0 24.0 36.0 49.0 70.0 81.0 96.0 130.0
E2-05
(E5-05)
Motor line-to-line resistance
Ω
0.316 0.269 0.155 0.122 0.088 0.092 0.046 0.029 0.025 0.020 0.014
E2-06
(E5-06)
Motor leak inductance
% 23.5 20.7 18.8 19.9 20.0 20.0 20.0 20.0 20.0 20.0 20.0
E2-10
Motor iron loss for torque com-
pensation
W 586 750 925 1125 1260 1600 2150 2850 3200 3700 4700
L2-02
Momentary power loss ridethru
time
sec 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0
L2-03 Min. baseblock time
sec 1.0 1.0 1.0 1.0 1.0 1.0 4.0 4.0 4.0 4.0 4.0
L2-04 Voltage recovery time
sec 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6
