16.2 List of Parameters
16.2.2 List of Parameters
16-25
16
Parameter Lists
PnB09
2
/SEL3; /JOG2
0000h to
0003h
–
0000h All
After
restart
Setup
page
6-6
PnB0A
2
/SEL4; /JOG3
0000h to
0003h
–
0000h All
After
restart
Setup
page
6-6
PnB0B
2
/SEL5
0000h to
0003h
–
0000h All
After
restart
Setup
page
6-7
PnB0C
2
/SEL6
0000h to
0003h
–
0000h All
After
restart
Setup
page
6-7
PnB0D
2
/SEL7
0000h to
0003h
–
0000h All
After
restart
Setup
page
6-7
Continued on next page.
Continued from previous page.
Parameter
No.
Size
Name
Setting
Range
Setting
Unit
Default
Setting
Applicable
Motors
When
Enabled
Classi-
fication
Refer-
ence
0000h
• When /MODE signal is ON (closed) (mode 0): The /SEL3 signal is active when ON
(closed).
• When /MODE signal is OFF (open) (mode 1): The /JOG2 signal is active when ON
(closed).
0001h
• When /MODE signal is ON (closed) (mode 0): The /SEL3 signal is active when OFF
(open).
• When /MODE signal is OFF (open) (mode 1): The /JOG2 signal is active when OFF (open).
0002h
• When /MODE signal is ON (closed) (mode 0): The /SEL3 signal is always active.
• When /MODE signal is OFF (open) (mode 1): The /JOG2 signal is always active.
0003h
• When /MODE signal is ON (closed) (mode 0): The /SEL3 signal is always inactive.
• When /MODE signal is OFF (open) (mode 1): The /JOG2 signal is always inactive.
0000h
• When /MODE signal is ON (closed) (mode 0): The /SEL4 signal is active when ON
(closed).
• When /MODE signal is OFF (open) (mode 1): The /JOG3 signal is active when ON
(closed).
0001h
• When /MODE signal is ON (closed) (mode 0): The /SEL4 signal is active when OFF
(open).
• When /MODE signal is OFF (open) (mode 1): The /JOG3 signal is active when OFF (open).
0002h
• When /MODE signal is ON (closed) (mode 0): The /SEL4 signal is always active.
• When /MODE signal is OFF (open) (mode 1): The /JOG3 signal is always active.
0003h
• When /MODE signal is ON (closed) (mode 0): The /SEL4 signal is always inactive.
• When /MODE signal is OFF (open) (mode 1): The /JOG3 signal is always inactive.
0000h The /SEL5 signal is active when ON (closed).
0001h The /SEL5 signal is active when OFF (open).
0002h The /SEL5 signal is always active.
0003h The /SEL5 signal is always inactive.
0000h The /SEL6 signal is active when ON (closed).
0001h The /SEL6 signal is active when OFF (open).
0002h The /SEL6 signal is always active.
0003h The /SEL6 signal is always inactive.
0000h The /SEL7 signal is active when ON (closed).
0001h The /SEL7 signal is active when OFF (open).
0002h The /SEL7 signal is always active.
0003h The /SEL7 signal is always inactive.
