xiii
LowScan
- Low Scan Relay
FirstScanRunning SB000003 After Low Scan Start,Only 1 Scan ON
OnAfter - Start-up Relay
FiveSecond SB00003A After 5.0s,Scan Start-up Relay
OneSecond SB000038 After 1.0s,Scan Start-up Relay
TwoSecond SB000039 After 2.0s,Scan Start-up Relay
PulseEvery - Sampling Relay
HalfSecond SB000034 0.5s Sampling Relay
OneMinute SB000037 60.0s Sampling Relay
OneSecond SB000035 1.0s Sampling Relay
TwoSecond SB000036 2.0s Sampling Relay
SquareWave - Flicker Relay
HalfSecond SB000031 0.5s Flicker Relay
OneScan SB000030 1 Scan Flicker Relay
OneSecond SB000032 1.0s Flicker Relay
TwoSecond SB000033 2.0s Flicker Relay
ScanTime
- Scan Time
ExecutionCurrentValue SW00014 Execution Scan Current Value (0.1ms)
High - High Scan
CurrentValue SW00005 High Scan Current Value (0.1ms)
ExceededCount SW00044 High Scan Over Counter
MaximumValue SW00006 High Scan Maximum Value (0.1ms)
SetValue SW00004 High Scan Set Value (0.1ms)
Low - Low Scan
CurrentValue SW00011 Low Scan Current Value (0.1ms)
MaximumValue SW00012 Low Scan Maximum Value (0.1ms)
SetValue SW00010 Low Scan Set Value (0.1ms)
ExceededCount SW00046 Low Scan Over Counter
(continued)
Variable Name Register Comments
