YASKAWA JEPMC-MP2300-Y Series User Manual

xiv
 System Variables (Sorted by Register)
Register Variable Name Comments
SB000001 HighScan.FirstScanRunning After High Scan Start,Only 1 Scan ON
SB000003 LowScan.FirstScanRunning After Low Scan Start,Only 1 Scan ON
SB000004
OnCoil
Always ON
SB000010 HighScan.SquareWave.OneScan 1 Scan Flicker Relay
SB000011 HighScan.SquareWave.HalfSecond 0.5s Flicker Relay
SB000012 HighScan.SquareWave.OneSecond 1.0s Flicker Relay
SB000013 HighScan.SquareWave.TwoSecond 2.0s Flicker Relay
SB000014 HighScan.PulseEvery.HalfSecond 0.5s Sampling Relay
SB000015 HighScan.PulseEvery.OneSecond 1.0s Sampling Relay
SB000016 HighScan.PulseEvery.TwoSecond 2.0s Sampling Relay
SB000017 HighScan.PulseEvery.OneMinute 60.0s Sampling Relay
SB000018 HighScan.OnAfter.OneSecond After 1.0s,Scan Start-up Relay
SB000019 HighScan.OnAfter.TwoSecond After 2.0s,Scan Start-up Relay
SB00001A HighScan.OnAfter.FiveSecond After 5.0s,Scan Start-up Relay
SB000030 LowScan.SquareWave.OneScan 1 Scan Flicker Relay
SB000031 LowScan.SquareWave.HalfSecond 0.5s Flicker Relay
SB000032 LowScan.SquareWave.OneSecond 1.0s Flicker Relay
SB000033 LowScan.SquareWave.TwoSecond 2.0s Flicker Relay
SB000034 LowScan.PulseEvery.HalfSecond 0.5s Sampling Relay
SB000035 LowScan.PulseEvery.OneSecond 1.0s Sampling Relay
SB000036 LowScan.PulseEvery.TwoSecond 2.0s Sampling Relay
SB000037 LowScan.PulseEvery.OneMinute 60.0s Sampling Relay
SB000038 LowScan.OnAfter.OneSecond After 1.0s,Scan Start-up Relay
SB000039 LowScan.OnAfter.TwoSecond After 2.0s,Scan Start-up Relay
SB00003A LowScan.OnAfter.FiveSecond After 5.0s,Scan Start-up Relay
SW00004 ScanTime.High.SetValue High Scan Set Value (0.1ms)
SW00005 ScanTime.High.CurrentValue High Scan Current Value (0.1ms)
SW00006 ScanTime.High.MaximumValue High Scan Maximum Value (0.1ms)
SW00010 ScanTime.Low.SetValue Low Scan Set Value (0.1ms)
SW00011 ScanTime.Low.CurrentValue Low Scan Current Value (0.1ms)
SW00012 ScanTime.Low.MaximumValue Low Scan Maximum Value (0.1ms)
SW00014 ScanTime.ExecutionCurrentValue Execution Scan Current Value (0.1ms)
SW00015 Clock.Year Calendar:Year
SW00016 Clock.MonthDate Calendar:Month Day
SW00017 Clock.HoursMinutes Calendar:Hours Minutes
SW00018 Clock.Second Calendar:Seconds
SW00019
Clock.
DayOfWeek
Calendar:Day of week
SW00020 CPU.Info.SoftwareVersion System Program Software Number
SL00026 CPU.Info.MemorySizeAvailable Available PRG Memory (BYTE)
SL00028 CPU.Info.MemorySizeTotal All Module Memory (BYTE)
SB000400 CPU.Status.Ready
READY (1=Normal,0=Converse/Own
Diagnose Unusual)
SB000401 CPU.Status.Running RUN (1=Driving,0=Driving Stop)
SB000402 CPU.Status.Alarm ALARM (1=Warning,0=Normal)
SB000403 CPU.Status.Error ERROR (1=Unusual,0=Normal)
SB000406 CPU.Status.WritingToFlash FLASH (1=FLASH Driving)
SB000407 CPU.Status.WriteEnable WEN (Write:1=Possible,0=Impossible)
