3.4
I/O Modules (Optional)
3-25
( 2 ) External Appearance
[ a ] LIO-01 Module [ b ] LIO-02 Module
LED indicators
I/O connector
Switch
LIO-01
LD5
LD6
LD7
LD8
LD1
LD2
LD3
LD4
MODE
I/O
LED indicators
I/O connector
Switch
LIO-02
LD5
LD6
LD7
LD8
LD1
LD2
LD3
LD4
MODE
I/O
