YASKAWA JEPMC-MP2300-Y Series User Manual

3
Module Specifications
3.4.1
LIO-01/LIO-02 Modules
3-26
[ c ] LED Indicators and Switch Settings
The LIO-01 and LIO-02 Module status display LED indicators (LD1 to LD8) change based on the
SW1 rotary switch settings (setting range: 0 to 5). The following table shows the indicator display for
DI and DO status according to the SW1 setting.
.
SW1
LED
No.
Status When Lit LED No. Status When Lit
0
(Board Status
Indicator)
LD1
LD2
LD3
LD4
Normal (Error when not lit)
One of the inputs D1_00 to DI_07 is ON.
One of the outputs DO_00 to DO_07 is ON.
Pulse A/B input. The Phase A/B is ON.
LD5
LD6
LD7
LD8
Normal (Error when not lit)
One of the inputs DI_08 to DI_15 is ON.
One of the outputs DO_08 to DO_15 is ON.
Pulse Z input. The Phase Z is ON.
1
(DI Input
Indicator 1)
LD1
LD2
LD3
LD4
DI_00 is ON.
DI_01 is ON.
DI_02 is ON.
DI_03 is ON.
LD5
LD6
LD7
LD8
DI_04 is ON.
DI_05 is ON.
DI_06 is ON.
DI_07 is ON.
2
（
DI Input
Indicator 2)
LD1
LD2
LD3
LD4
DI_08 is ON.
DI_09 is ON.
DI_10 is ON.
DI_11 is ON.
LD5
LD6
LD7
LD8
DI_12 is ON.
DI_13 is ON.
DI_14 is ON.
DI_15 is ON.
3
（
DO Output
Indicator 1)
LD1
LD2
LD3
LD4
DO_00 is ON.
DO_01 is ON.
DO_02 is ON.
DO_03 is ON.
LD5
LD6
LD7
LD8
DO_04 is ON.
DO_05 is ON.
DO_06 is ON.
DO_07 is ON.
4
（
DO Output
Indicator 2)
LD1
LD2
LD3
LD4
DO_08 is ON.
DO_09 is ON.
DO_10 is ON.
DO_11 is ON.
LD5
LD6
LD7
LD8
DO_12 is ON.
DO_13 is ON.
DO_14 is ON.
DO_15 is ON.
5
(PI Input
Indicator)
LD1
LD2
LD3
LD4
Pulse A input
Pulse B input
Pulse Z input
－
LD5
LD6
LD7
LD8
Coincidence detection
Phase-Z latch
DI latch
－
LD3
LD2
LD1
LD4
LD7
LD6
LD5
LD8
Indicators SW1
0
5
1
2
3
4
6
7
8
9
