3.4
I/O Modules (Optional)
3-45
[ c ] LED Indicators
The following table shows the LIO-04/LIO-05 status when the each indicator lamp is lit or unlit.
( 3 ) Specifications
The hardware specifications and temperature characteristics of LIO-04/LIO-05 Module are as fol-
lows.
[ a ] Hardware Specifications
Indicator Color Status When Lit Status When Unlit
RUN Green
Normal operation Error occurrence
FUSE Red
One or some of the output protection
fuses is blown out.
All the output protection fuses are
normal.
FUSERUN
Item Specifications
Classification
I/O Module
Name
LIO-04 LIO-05
Model
JAPMC-IO2303 JAPMC-IO2304
Digital Input
32 inputs
24-VDC
±
20% (+19.2V to +28.8V), 4.1 mA (TYP),
combined sink mode/source mode inputs (DI-00, -01, -16, and -17 also used for interrupts)
Number of simultaneously ON inputs: 16 (8/connector with 24 VDC),
10 (5/connector with 28.8 VDC)
*For details, refer to [ b ] Number of Simultaneously ON
Inputs - Ambient Temperature Characteristics.
Digital Output
32 outputs
24-VDC
±
20% (+19.2V to +28.8V),
100 mA max.,
transistor outputs, sink mode outputs
32 outputs
24-VDC
±
20% (+19.2V to +28.8V),
100 mA max.,
transistor outputs, source mode outputs
LED Indicators
RUN (green)
FUSE (red)
Connectors
CN1: I/O connector
CN2: I/O connector
Current Consumption
500mA max.
Dimensions (mm)
125
× 95 (H× D)
Mass
80 g
To Next Page
