YASKAWA JEPMC-MP2300-Y Series User Manual

3
Module Specifications
3.4.3
LIO-04/LIO-05 Modules
3-46
[ b ] Number of Simultaneously ON Inputs - Ambient Temperature Characteristics
The following graph shows the number of inputs that can be simultaneously ON depending on the
ambient temperature.
0
0
10
5
15
20
25
30
35
(Number of inputs)
10 20 30
Ambient Temperature
40 50 60 㧔㧕
(10 inputs at 55㧕
(16 inputs at 55㧕
(32 inputs at 41㧕
(Input voltage: 24 VDC)
(Input voltage: 24 VDC)
(32 inputs
at 28㧕
Number of
Simultaneously
ON Inputs
