Module Specifications
3.5.2
217IF-01 Module
3-56
( 3 ) Specifications
The specifications of 217IF-01 Module are as follows.
[ a ] Hardware Specifications
[ b ] Communication Specifications
îš„
RS-232C Communication Specifications
* The baud rate depends on the connected devices.
Item Specifications
Classification
Communication Module
Name
217IF-01
Model
JAPMC-CM2310
Communication Ports
RS-232C 1 port (PORT)
RS422/485 1 port (RS422/485)
Indicators
Module status LED indicators
RUN (green)
ERR (red)
STRX (green)
TRX (green)
Setting Switches
−
485
INIT
TEST
Current Consumption
500 mA max.
Dimensions (mm)
125
×
95 (H
×
D)
Mass
90 g
Item Specifications
Interface
1 port (PORT)
Connectors
9-pin D-sub (female)
Transmission Distance
15 m max.
Baud Rate*
9.6/14.4/19.2/28.8/38.4/48.0/57.6/76.8 Kbps
Access Mode
Asynchronous (start-stop synchronization)
Communication Modes
Message communication, engineering communication
Communication Protocols
MEMOBUS, MELSEC, OMRON, Non-procedure
Media Access Control
Method
1:1
Transmission Format
(Can be set)
Data length: 7 or 8 bits
Stop bits: 1 or 2 bits
Parity: Odd, even, or none
