YASKAWA JEPMC-MP2300-Y Series User Manual

3.5
Communication Modules (Optional)
3-59
( 3 ) Specifications
The specifications of 260IF-01 Module are as follows.
[ a ] Hardware Specifications
[ b ] Communication Specifications

RS-232C Communication Specifications
Item Specifications
Classification
Communication Module
Name
260IF-01
Model
JAPMC-CM2320
Communication Ports
RS-232C 1 port (PORT)
DeviceNet 1 port (DeviceNet)
Indicators
Module status LED indicators
MS (green, red)
NS (green, red)
Setting Switches
DR0
DR1
×
1
×
2
INIT
TEST
×
10
×
1
Current Consumption
500 mA max.
Dimensions (mm)
125
×
95 (H
×
D)
Mass
85
ｇ
Item Specifications
Connectors
9-pin D-sub
(female)
Transmission Distance
15 m max.
Baud Rate
9,600 or 19,200 bps
Access Mode
Asynchronous (start-stop synchronization)
Communication Modes
Message communication, engineering communication
Communication Protocols
MEMOBUS, MELSEC, OMRON, Non-procedure
Media Access Control
Method
1:1
Transmission Format (Can
be set)
Data length: 7 or 8 bits
Stop bits: 1 or 2 bits
Parity: Odd, even, or none
