Mounting and Wiring
4.4.1
LIO-01/LIO-02 Modules
4-28
( 4 ) Connector Pin Arrangement
The following table shows the connector pin arrangement for LIO-01/LIO-02 Modules viewing from
the wiring side.

P: Power supply input; I: Input signal; O: Open-collector output
Pin
Number
Signal
Name
I/O Remarks
Pin
Number
Signal
Name
I/O Remarks
A1
PA I
Phase-A pulse (+) B1
PAL I
Phase-A pulse (
−)
A2
PB I
Phase-B pulse (+) B2
PBL I
Phase-B pulse (
−)
A3
PC I
Phase-Z pulse (+) B3
PCL5 I
Phase-Z pulse
(
−
5-V input)
A4
GND I
Pulse input ground B4
PCL12 I
Phase-Z pulse
(
−
12-V input)
A5
DO_COM P
Output common B5
DO_COM P
Output common
A6
DO_24V P
+24 V input B6
DO_24V P
+24 V input
A7
DO_15 O
Output 15 B7
DO_14 O
Output 14
A8
DO_13 O
Output 13 B8
DO_12 O
Output 12
A9
DO_11 O
Output 11 B9
DO_10 O
Output 10
A10
DO_09 O
Output 9 B10
DO_08 O
Output 8
A11
DO_07 O
Output 7 B11
DO_06 O
Output 6
A12
DO_05 O
Output 5 B12
DO_04 O
Output 4
A13
DO_03 O
Output 3 B13
DO_02 O
Output 2
A14
DO_01 O
Output 1 B14
DO_00 O
Output 0
A15
DI_15 I
Input 15 B15
DI_14 I
Input 14
A16
DI_13 I
Input 13 B16
DI_12 I
Input 12
A17
DI_11 I
Input 11 B17
DI_10 I
Input 10
A18
DI_09 I
Input 9 B18
DI_08 I
Input 8
A19
DI_07 I
Input 7 B19
DI_06 I
Input 6
A20
DI_05 I
Input 5 B20
DI_04 I
Input 4
A21
DI_03 I
Input 3 B22
DI_02 I
Input 2
A22
DI_01 I
Input 1 B22
DI_00 I
Input 0
A23
DI_COM0 P
Input common 0 B23
DI_COM1 P
Input common 1
A24
FG −
Frame ground B24
FG −
Frame ground
B1A1
B24A24
