4.5
Communication Module (Optional) Connections
4-63
[ b ] Ethernet Connections
This section explains connections to the Ethernet using 10Base-T.
The maximum length between the end nodes is 500 m with 10Base-T connections.
< Connection Example 1 >
< Connection Example 2 >
HUB Repeater
MP2300
218IF-01
Other station
Repeater HUB
Other station Other station
Other station
100 m 100 m
100 m
100 m
100 m
100 m 100 m
100 m
10Base-T
MP2300
YASKAWA
218IF-01
Option
Option
10Base-T (cross cable: 100 m max.)
MP2300
218IF-01
MP2300
YASKAWA
218IF-01
Option
Option
