YASKAWA JEPMC-MP2300-Y Series User Manual

4
Mounting and Wiring
4.5.1
218IF-01 Module
4-62
■
For 25-pin D-sub Remote Stations
■
For 9-pin D-sub Remote Station Meeting Yaskawa Specifications
■
For DOS/V Computer Remote Stations
MP2300
(
PORT
Connector)
Cable Connection and
Signal Direction
Remote Station
(25-pin
D-sub)
Signal Name Pin No. Pin No. Signal Name
FG
11
FG
SD (TXD)
22
SD (TXD)
RD (RXD)
33
RD (RXD)
RS
(
RTS
)
44
RS
(
RTS
)
CS (CTS)
55
CS (CTS)
−
66
DSR (DR)
SG
(
GND
)
77
SG
(
GND
)
−
88
CD
ER (DTR)
920
DTR (ER)
MP2300
(
PORT
Connector)
Cable Connection and
Signal Direction
Remote Station
(9-pin D-sub)
(Yaskawa Specifications)
Signal Name Pin No. Pin No. Signal Name
FG
11
FG
SD (TXD)
22
SD (TXD)
RD (RXD)
33
RD (RXD)
RS
(
RTS
)
44
RS
(
RTS
)
CS (CTS)
55
CS
(CTS)
−
66
DR (DSR)
SG
(
GND
)
77
SG
(
GND
)
−
88
CD
ER (DTR)
99
ER
(
DTR
)
MP2300
(
PORT
Connector)
Cable Connection and
Signal Direction
DOS/V Computer
(9-pin D-sub male
)
Signal Name Pin No. Pin No. Signal Name
FG
11
FG
SD (TXD)
22
RD (RXD)
RD (RXD)
33
SD (TXD)
RS
(
RTS
)
44
ER (DTR)
CS (CTS)
55
SG
(
GND
)
−
66
DR (DSR)
SG
(
GND
)
77
RS
(
RTS
)
−
88
CS (CTS)
ER (DTR)
99
−
