YASKAWA JEPMC-MP2300-Y Series User Manual

4
Mounting and Wiring
4.5.4
261IF-01 Module
4-72
[ b ] PROFIBUS Connector
The PROFIBUS connector is used to connect to masters via a PROFIBUS connection.
( 4 ) Module Connection Examples
[ a ] PORT Connector Connections
For information on how to connect the PORT connector, refer to 4.5.1 ( 4 ) [ a ] PORT Connector
Connections on page 4-61.
[ b ] PROFIBUS Connections
The 261IF-01 Module only supports slave mode. The slave address can be set between 1 and 64.
Pin
Number
Signal Name Description
Pin
Number
Signal
Name
Description
1 −−6
+5V
External power supply
2 −−7 −−
3
TXD/RDX+
Transmission and
reception (+)
8
TXD/RDX-
Transmission and
reception (
−
)
4
RTS
Transmission request 9 −−
5
GND
Ground
1
69
5
InverterSERVOPACK Machine-side I/O signal
MP2300
261IF-01
PROFIBUS-DP Master (Class 1 master)
DC24V
DC 0V
MP2300
YASKAWA
TEST
Option
RDY
ALM
TX
RUN
ERR
BAT
MON
CNFG
INT
SUP
STOP
SW1
OFF ON
BATTERY
CPU I/O
Option
M-I/II
ERR
TRXSTRX
RUN
261IF-01
TEST
INIT
ONOFF
10
1
PORT
PROFIBUS
YASKAWA SERVOPACK
200V
SGDS-01A12A
SW1
CHARGE
C
N
3
A/B
C
N
1
N
2
C
N
4
L1
L2
L2C
L1C
B1/
B2
U
V
W
C
N
6
