2.1
Model System Startup Procedure
2-29
3.
Set the fixed parameters for axis 1.
Select Axis 1 from the axis selection box at the top-left of the window and select mm under No.
4 Reference unit selection on the Fixed Parameter Tab Page.
4.
In the Engineering Manager Window, select File (F) - Save (S) to save the settings for
axis 1 fixed parameters.
5.
Refer to steps 3 and 4 to set and save the fixed parameters for axis 2 using the same
procedure as for axis 1.
The process for saving fixed parameter settings has now been completed. Next, save the SERVO-
PACK parameters.
To Next Page
