Agilent Technologies 4294A User Manual

386 Appendix B
Key Definitions
Softkeys displayed by pressing the [Sweep] key
BIAS MODE [ ] ä Displays Table B-51, “DC bias mode (DC Bias Mode) menu,” on page 387. In
[ ] of the softkey label, the currently selected dc bias mode (voltage mode:
[VOLT] or current mode: [CURR]) is displayed.
(N/A)
DC BIAS VOLTAGE Sets the dc bias voltage of the segment. DCV <value>
DC BIAS CURRENT Sets the dc bias current of the segment. DCI <value>
more 2/3 Displays Table B-50, “Segment edit (Edit Segment) menu (3/3),” on page 386. (N/A)
done Stores the edited list sweep segment and returns to Table B-47, “List sweep (List
Sweep) menu,” on page 384.
SDON
cancel Cancels the editing of the list sweep segment and returns to Table B-47, “List
sweep (List Sweep) menu,” on page 384.
SQUI
Table B-50 Segment edit (Edit Segment) menu (3/3)
Key operation: [Sweep] - EDIT LIST - EDIT - more 1/3 - more 2/3
[Sweep] - EDIT LIST - ADD - more 1/3 - more 2/3
Softkey Function GPIB command
BANDWIDTH [ ] ä Displays Table B-33, “Measurement bandwidth (Bandwidth) configuration
menu,” on page 376. In [ ] of the softkey label, the currently selected
measurement bandwidth is displayed.
(N/A)
POINT AVG FACTOR Sets the point averaging factor for the segment (averaging count performed for
each measurement point). Specify an integer between 1 and 256.
PAVERFACT <value>
MKR ® START Enters the frequency at the current marker position to the sweep start value of the
segment.
MKRSTAR
MKR ® STOP Enters the frequency at the current marker position to the sweep stop value of the
segment.
MKRSTOP
MKR ® CENTER Enters the frequency at the current marker position to the sweep center value of
the segment.
MKRCENT
more 3/3 Displays Table B-48, “Segment edit (Edit Segment) menu (1/3),” on page 385. (N/A)
done Stores the edited list sweep segment and returns to Table B-47, “List sweep (List
Sweep) menu,” on page 384.
SDON
cancel Cancels the editing of the list sweep segment and returns to Table B-47, “List
sweep (List Sweep) menu,” on page 384.
SQUI
Table B-49 Segment edit (Edit Segment) menu (2/3)
Key operation: [Sweep] - EDIT LIST - EDIT - more 1/3
[Sweep] - EDIT LIST - ADD - more 1/3
Softkey Function GPIB command
