3.4 Functions Selected from the Main Menu
HA-8190V 3-11
 [Maintenance menu] screen (7000)
Option Description Page
Tube wash (7100) Washes the tubes. 4-26
Piercing nozzle
(7200)
Moves the piercing nozzle to a position that makes it easy to replace or clean. 4-17
4-31
Dilution container
(7300)
Drains the dilution container in preparation for cleaning. 4-36
4-39
Sample tube spin
unit (7400)
Moves the sample tube spinning unit to a position that makes it easy to clean. 4-33
Drain menu (7500) Eluent A (7510): Drains fluid from the eluent A chamber. 1-39
4-55
Eluent B (7520): Drains fluid from the eluent B chamber.
Eluent CV (7530): Drains fluid from the eluent CV chamber.
Hemolysis washing sol. (7540): Drains hemolysis washing solution from the tube.
Priming menu (7600) Automatic (7610): Removes air from the eluent A tube, eluent B
tube, eluent CV tube, fluid pump and damper by
priming, and stops automatically.
4-52
Pump (7620): Pumps eluent A to the column.
Eluent A (7630): Removes air from the eluent A tube.
Eluent B (7640): Removes air from the eluent B tube.
Eluent CV (7650): Removes air from the eluent CV tube.
Damper (7660): Removes air from the fluid pump and damper by
priming.
Hemolysis washing sol. (7670): Removes air from the hemolysis washing solution
tube.
Maintenance log
menu (7700)
Piercing nozzle (7710): Records the date when cleaning the piercing
nozzle.
4-53
Dilution container (7720): Records the date when cleaning the dilution
container.
Others (7730): Records the dates when the nozzle mesh filters
and drain pinch valve tubes were replaced.
Maintenance info.
(7800)
Displays the dates that maintenance tasks were last performed on parts that
require periodic maintenance and the number of measurements since those dates.
4-54
