Arkray ADAMS A1c User Manual

3.6 Measurement Results
HA-8190V 3-19
d Touch .
• If <All> is selected for <Range of results>, printing/transmission will start.
• If another option is selected for <Range of results>, go to step e.
e Set the range of measurement results to print/transmit according
to the option set in <Range of results>.
When <Meas No.> is selected:
• Set a range of measurement numbers.
• Settable range: 0 to 9999
When <Port No.> is selected:
• Set a range of port number.
• Settable range: 0 to 9999
When <Sample ID> is selected:
• Enter a sample ID.
• See “ Entering IDs” on page 1-49.
• IDs can also be entered with the optional hand-held barcode
reader.
Setup item Description (default bolded)
Date (DD-MM-YY) Set a range of measurement dates. The end date (right) must be the same as or later than
the start date (left).
Settable range: 01-01-2000 to 31-12-2099
Measurement Select the type of measurement from:
Normal & STAT meas., Normal measurement, STAT measurement,
Control measurement, All
Results Select the type of results from:
All: All results
Normal results only: Normal results only
Include abnormal results: Normal and abnormal results
(Results for misread barcodes are not included.)
Barcode misread: Barcode misread results only
Range of results Select how you want to specify a range of results from:
All: All results
Meas. No.: Measurement number
Port No.: Port number
Sample ID: Sample ID
Meas. mode Select one or both of the measurement modes for which to print/transmit results. The default
is the current measurement mode.
Variant: Variant mode
Fast: Fast mode
Fast & Variant: Both modes
REFERENCE:
 If “Not found” appears on the display:
No match is found in the memory. Touch to return to the screen shown in step c.
 Press or to stop printing/transmission.
OK
OK
Stop
