Chapter 4 Maintenance

HA-8190V 4-22

8 Complete maintenance.

a Select <Done> for the maintenance tasks you performed.

• Touch <Not yet> to change to <Done>.

b Touch .

• The instrument will record the maintenance date.

• The [Maintenance menu] screen will appear again.

c Touch to return to the standby screen.
