AT32F421 Series Reference Manual

2022.11.11 Page 74 Rev 2.02

5.8.4 Flash status register (FLASH_STS)

Bit

Abbr.

Reset value

Type

Description

Bit 31: 6

Reserved

0x0000000

resd

Kept at its default value

Bit 5

ODF

rw1c

Operation done flag

This bit is set by hardware when Flash memory

operations (program/erase) are complete. It is

cleared by writing “1”.

Bit 4

EPPERR

rw1c

Erase/program protection error

This bit is set by hardware when programming the

erase/program- protected Flash memory address. It

is cleared by writing “1”.

Bit 3

Reserved

resd

Kept at its default value.

Bit 2

PRGMERR

rw1c

Programming error

When the Flash programming address is in “non-erase”

state, this bit is set by hardware. It is cleared by writing

“1”.

Bit 1

Reserved

resd

Kept at its default value.

Bit 0

OBF

Operation busy flag

When this bit is set, it indicates that Flash memory

operation is in progress. It is cleared when operation is

complete.
