6.2.10 Peripheral multiplexed function configuration
When IOMUX multiplexed function is needed:
To use a peripheral pin as a multiplexed output, the corresponding pin should be configured as
multiplexed push-pull/open-drain output.
To use a peripheral pin as a MUX input, the corresponding pin configured as floating input/pull-
up/pull-down input.
For ADC peripherals, the pin corresponding to analog channel should be configured as analog
input/output mode.
For I2C peripherals that intend to use a pins as bidirectional function, the corresponding pin should
be configured as open-drain mode.
6.2.11 IOMUX map priority
Almost all peripherals can be configured as corresponding multiplexed functions using GPIOx_MUXL or
GPIOx_MUXH registers, except for a few pins that might be occupied by hardware directly.
Some of the pins, no matter whatever GPIO mode configuration, are always owned by specific hardware
feature directly.
Table 6-4 Hardware preemption
Once enabled, PA0 pin acts as WKUP1
function of PWC.
Once enabled, PB5 pin acts as WKUP6
function of PWC
Once enabled, PB15 pin acts as WKUP7
function of PWC
Once enabled, PA0 pin acts as WKUP2
function of PWC
(ERTC_CTRL[23:21] !=3’b000)|(ERTC_CTRL[11] !=0)|
(ERTC_TAMP[0] != 0)
Once enabled, PC13 pin acts as RTC
channel input/output
Once enabled, PC14 pin acts as LEXT
channel
Once enabled, PC15 pin acts as LEXT
channel
Once enabled, PF0 pin acts as HEXT
channel
Once enabled, PF1 pin acts as HEXT
channel
6.2.12 External interrupt/wake-up lines
Each pin can be used as an external interrupt input and thus the corresponding pin must be configured
as input mode.
6.3 GPIO registers
Table 6-5 lists GPIO register map and their reset values. These peripheral registers must be
accessed by bytes (8-bit), half-words (16-bit) or words (32 bits).
Table 6-5 GPIO register map and reset values
