AudioCodes Mediant 500L MSBR

User's Manual 140 Document #: LTRT-10466
Mediant 500L MSBR
 To configure IP network interfaces:
1. Open the Interface Table page (Configuration tab > VoIP menu > Network > IP
Interfaces Table).
2. Click Add; a dialog box appears.
3. Configure the IP network interface according to the parameters described in the table
below.
4. Click Submit.
To view configured network interfaces that are currently active, click the IP Interface
Status Table button. For more information, see ''Viewing Active IP Interfaces'' on page
693.
Table 15-2: Interface Table Parameters Description
Parameter Description
Table parameters
Index
CLI: network-if
[InterfaceTable_Index]
Table index row of the interface.
The range is 0 to 11.
Web: Application Type
EMS: Application Types
CLI: application-type
[InterfaceTable_Application
Types]
Defines the applications allowed on the interface.
 [0] OAMP = Operations, Administration, Maintenance and
Provisioning (OAMP) applications (e.g., Web, Telnet, SSH, and
SNMP).
 [1] Media = Media (i.e., RTP streams of voice).
 [2] Control = Call Control applications (e.g., SIP).
 [3] OAMP + Media = OAMP and Media applications.
 [4] OAMP + Control = OAMP and Call Control applications.
 [5] Media + Control = Media and Call Control applications.
 [6] OAMP + Media + Control = All application types are allowed
on the interface.
