AudioCodes Mediant 500L MSBR

User's Manual 15. Network
Version 6.8 141 Mediant 500L MSBR
Parameter Description
Web: Interface Mode
[InterfaceTable_InterfaceMod
e]
Defines the method that the interface uses to acquire its IP address.
 [3] IPv6 Manual Prefix = IPv6 manual prefix IP address
assignment. The IPv6 prefix (higher 64 bits) is set manually while
the interface ID (the lower 64 bits) is derived from the device's
MAC address.
 [4] IPv6 Manual = IPv6 manual IP address (128 bits) assignment.
 [10] IPv4 Manual = IPv4 manual IP address (32 bits) assignment.
Web/EMS: IP Address
CLI: ip-address
[InterfaceTable_IPAddress]
Defines the IPv4/IPv6 address, in dotted-decimal notation.
Web/EMS: Prefix Length
CLI: prefix-length
[InterfaceTable_PrefixLengt
h]
Defines the prefix length of the related IP address. This is a
Classless Inter-Domain Routing (CIDR)-style representation of a
dotted-decimal subnet notation. The CIDR-style representation uses
a suffix indicating the number of bits which are set in the dotted-
decimal format. For example, 192.168.0.0/16 is synonymous with
192.168.0.0 and subnet 255.255.0.0. This CIDR lists the number of
‘1’ bits in the subnet mask (i.e., replaces the standard dotted-decimal
representation of the subnet mask for IPv4 interfaces). For example,
a subnet mask of 255.0.0.0 is represented by a prefix length of 8
(i.e., 11111111 00000000 00000000 00000000) and a subnet mask
of 255.255.255.252 is represented by a prefix length of 30 (i.e.,
11111111 11111111 11111111 11111100).
The prefix length is a Classless Inter-Domain Routing (CIDR) style
presentation of a dotted-decimal subnet notation. The CIDR-style
presentation is the latest method for interpretation of IP addresses.
Specifically, instead of using eight-bit address blocks, it uses the
variable-length subnet masking technique to allow allocation on
arbitrary-length prefixes.
The prefix length for IPv4 must be set to a value from 0 to 30. The
prefix length for IPv6 must be set to a value from 0 to 64.
Web/EMS: Default Gateway
CLI: gateway
[InterfaceTable_Gateway]
Defines the IP address of the default gateway for the interface. When
traffic is sent from this interface to an unknown destination (i.e., not
in the same subnet and not defined for any static routing rule), it is
forwarded to this default gateway.
Note: When using both voice and data-routing functionalities, it is
recommended to set this Default Gateway's IP address in the same
subnet and VLAN ID as the IP address configured for data-routing.
Web/EMS: Interface Name
CLI: name
[InterfaceTable_InterfaceNa
me]
Defines a name for the interface. This name is used in various
configuration tables to associate the network interface with other
configuration entities such as Media Realms. It is also displayed in
management interfaces (Web, CLI, and SNMP) for clarity where it
has no functional use.
The valid value is a string of up to 16 characters.
Web/EMS: Primary DNS
CLI: primary-dns
[InterfaceTable_PrimaryDNS
ServerIPAddress]
(Optional) Defines the primary DNS server's IP address (in dotted-
decimal notation), which is used for translating domain names into IP
addresses for the interface.
By default, no IP address is defined.
