User's Manual 270 Document #: LTRT-10466
Mediant 500L MSBR
Parameter Description
Ingress Video Bandwidth
CLI: ingress-video-bandwidth
[BWProfile_IngressVideoBandwidth]
Defines the incoming video traffic threshold (in Kbps).
Total Egress Bandwidth
CLI: total-egress-bandwidth
[BWProfile_TotalEgressBandwidth]
Defines the total (video and audio) outgoing bandwidth
threshold (in Kbps).
Total Ingress Bandwidth
CLI: total-ingress-bandwidth
[BWProfile_TotalIngressBandwidth]
Defines the total (video and audio) incoming bandwidth
threshold (in Kbps).
Warning Threshold
CLI: warning-threshold
[BWProfile_WarningThreshold]
Defines the threshold (in percentage) of the bandwidth
thresholds that if exceeded is considered a Warning alarm
(Green-Yellow threshold). This applies to any of the
configured bandwidth thresholds. The Hysteresis is also
added to this Warning threshold. For example, if set to 70%
and the Hysteresis to 10%, when the current outgoing voice
traffic exceeds 80% of the configured threshold, the Yellow
state occurs and a Warning threshold alarm is sent if
'Generate Alarm' is set to Enable.
Hysteresis
CLI: hysteresis
[BWProfile_hysteresis]
Defines the bandwidth fluctuation (change) from the
bandwidth threshold value (in percentage). The threshold is
considered crossed if bandwidth exceeds the configured
threshold plus this hysteresis, and a Red state occurs. For
example, assume this parameter is set to 10% and the
configured bandwidth threshold is set to 64000 Kbps. If
current bandwidth reaches 70,400 Kbps (additional 10%),
the threshold is considered crossed.
Generate Alarm
CLI: generate-alarms
[BWProfile_GenerateAlarms]
Enables the generation of an SNMP alarm if the threshold
(with the hysteresis) is crossed.
[0] Disable (default)
[1] Enable
If enabled, an alarm is sent if one of the following scenarios
occurs:
Warning threshold is exceeded (Warning severity -
Yellow threshold).
Any configured bandwidth threshold is exceeded (Major
severity - Red threshold).
