 To configure calling name manipulation rules:
1. Open the required calling name manipulations page (Configuration tab > VoIP menu
> GW and IP to IP > Manipulations > Calling Name IP->Tel or Calling Name Tel-
>IP).
2. Click Add; the following dialog box appears:
Figure 26-3: Calling Name Manipulation IP2Tel - Rule Tab
3. Configure a manipulation rule according to the parameters described in the table
below.
4. Click Submit, and then save ("burn") your settings to flash memory.
Table 26-3: Calling Name Manipulation Tables Parameter Descriptions
Parameter Description
Index
[_Index]
Defines an index number for the new table record.
Manipulation Name
CLI: manipulation-name
[_ManipulationName]
Defines an arbitrary name to easily identify the manipulation rule.
The valid value is a string of up to 20 characters.
Matching Characteristics (Rule)
Web: Destination Prefix
CLI: dst-prefix
[_DestinationPrefix]
Defines the destination (called) telephone number prefix and/or suffix.
You can use special notations for denoting the prefix. For example,
[100-199](100,101,105) denotes a number that starts with 100 to 199
and ends with 100, 101 or 105. You can also use the $ sign to denote
calls without a called number. For a description of available notations,
see ''Dialing Plan Notation for Routing and Manipulation Tables'' on
page 777.
The default value is the asterisk (*) symbol (i.e., any destination prefix).
Web/EMS: Source Prefix
CLI: src-prefix
[_SourcePrefix]
Defines the source (calling) telephone number prefix and/or suffix.
You can use special notations for denoting the prefix. For example,
[100-199](100,101,105) denotes a number that starts with 100 to 199
and ends with 100, 101 or 105. You can also use the $ sign to denote
calls without a calling number. For a description of available notations,
see ''Dialing Plan Notation for Routing and Manipulation Tables'' on
page 777.
The default value is the asterisk (*) symbol (i.e., any source prefix).
Web: Calling Name Prefix Defines the caller name (i.e., caller ID) prefix.
