AudioCodes Mediant 500L MSBR

User's Manual 27. Routing
Version 6.8 411 Mediant 500L MSBR
Parameter Description

"x": represents single digits. For example, 10.8.8.xx denotes all
addresses between 10.8.8.10 and 10.8.8.99.
 "*": represents any number between 0 and 255. For example,
10.8.8.* denotes all addresses between 10.8.8.0 and
10.8.8.255.
For ENUM-based routing, enter the string "ENUM". The device
sends an ENUM query containing the destination phone number to
an external DNS server, configured in the Interface table. The
ENUM reply includes a SIP URI which is used as the Request-URI
in the subsequent outgoing INVITE and for routing (if a proxy is
not used). To configure the type of ENUM service (e.g.,
e164.arpa), use the EnumService parameter.
For LDAP-based routing, enter the string value "LDAP" for
denoting the IP address of the LDAP server. For more information,
see Routing Based on LDAP Active Directory Queries on page
226.
Notes:
 This field and any value assigned to it is ignored if you have
configured a destination IP Group for this routing rule (in the
'Dest IP Group ID' field).

To reject calls, enter the IP address 0.0.0.0. For example, if you
want to prohibit international calls, then in the 'Dest Phone
Prefix' field, enter 00 and in the 'Dest IP Address' field, enter
0.0.0.0.
 For routing calls between phones connected to the device (i.e.,
local routing), enter the device's IP address.
 When the device's IP address is unknown (e.g., when DHCP is
used), enter IP address 127.0.0.1.
 When using domain names, enter the DNS server's IP address
or alternatively, configure these names in the Internal DNS
table (see ''Configuring the Internal DNS Table'' on page 153).
Web: Port
EMS: Destination Port
CLI: dst-port
[PREFIX_DestPort]
Defines the destination port to where you want to route the call.
Web/EMS: Transport Type
CLI: transport-type
[PREFIX_TransportType]
Defines the transport layer type for sending the IP call:
 [-1] Not Configured
 [0] UDP
 [1] TCP
 [2] TLS
Note: When set to Not Configured (-1), the transport type defined
by the SIPTransportType parameter is used.
Web: Dest. IP Group ID
EMS: Destination IP Group ID
CLI: dst-ip-group-id
[PREFIX_DestIPGroupID]
Defines the IP Group to where you want to route the call. The SIP
INVITE message is sent to the IP address defined for the Proxy
Set ID associated with the IP Group.
Notes:
 If you select an IP Group, you do not need to configure a
destination IP address. However, if both parameters are
configured in this table, the INVITE message is sent only to the
IP Group (and not the defined IP address).
 If the destination is a User-type IP Group, the device searches
for a match between the Request-URI (of the received INVITE)
