 To configure a Classification rule:
1. Open the Classification Table page (Configuration tab > VoIP menu > SBC >
Routing SBC > Classification Table).
2. Click Add; the following dialog box appears:
Figure 36-2: Classification Table Page
3. Configure the Classification rule according to the parameters described in the table
below.
4. Click Submit, and then save ("burn") your settings to flash memory.
Table 36-1: Classification Table Parameter Descriptions
Parameter Description
Index
[Classification_Index]
Defines an index number for the new table record.
Classification Name
CLI: classification-name
[Classification_ClassificationName]
Defines an arbitrary name to easily identify the
Classification rule.
The valid value is a string of up to 20 characters. By default,
no name is defined.
Matching Characteristics - Rule
Message Condition
CLI: message-condition
[Classification_MessageCondition]
Assigns a Message Condition rule, which can be used to
classify the incoming SIP dialog. To configure Condition
rules, see ''Configuring Message Condition Rules'' on page
562.
Source SRD ID
CLI: src-srd-id
[Classification_SrcSRDID]
Defines an SRD ID of the incoming SIP dialog. To configure
SRDs, see ''Configuring SRDs'' on page 280.
By default, no SRD is defined.
Note: The SRDs are also associated with a port number as
defined by the SIP Interface used by the SRD (see
''Configuring SIP Interfaces'' on page 283).
