User's Manual 578 Document #: LTRT-10466
Mediant 500L MSBR
To configure an IP-to-IP Inbound Manipulation rule:
1. Open the IP to IP Inbound Manipulation page (Configuration tab > VoIP menu > SBC
> Manipulations SBC > IP to IP Inbound).
2. Click Add; the following dialog box appears:
Figure 37-2: IP to IP Inbound Manipulation Page - Add Dialog Box
3. Configure the IP-to-IP inbound manipulation rule according to the parameters
described in the table below.
4. Click Submit, and then save ("burn") your settings to flash memory.
Table 37-1: IP to IP Inbound Manipulation Parameter Descriptions
Parameter Description
Index
[IPInboundManipulation_Inde
x]
Defines an index number for the new table record.
Manipulation Name
CLI: manipulation-name
[IPInboundManipulation_Mani
pulationName]
Defines an arbitrary name to easily identify the manipulation rule.
The valid value is a string of up to 20 characters. By default, no
value is defined.
Matching Characteristics - Rule
Additional Manipulation
CLI: is-additional-manipulation
[IPInboundManipulation_IsAd
ditionalManipulation]
Determines whether additional SIP URI user part manipulation is
done for the table entry rule listed directly above it.
[0] No = (Default) Regular manipulation rule (not done in
addition to the rule above it).
[1] Yes = If the above row entry rule matched the call, consider
this row entry as a match as well and perform the manipulation
specified by this rule.
Note: Additional manipulation can only be done on a different SIP
URI, source or destination, to the rule configured in the row above
as configured by the 'Manipulated URI' parameter (see below).
Manipulation Purpose
CLI: purpose
[IPInboundManipulation_Mani
Defines the purpose of the manipulation:
[0] Normal = (Default) Inbound manipulations affect the routing
input and source and/or destination number.
