User's Manual 582 Document #: LTRT-10466
Mediant 500L MSBR
2. Click Add; the following dialog box appears:
Figure 37-3: IP to IP Outbound Manipulation Page - Add Dialog Box
3. Configure an IP-to-IP outbound manipulation rule according to the parameters
described in the table below.
4. Click Submit, and then save ("burn") your settings to flash memory.
Table 37-2: IP to IP Outbound Manipulation Table Parameter Description
Parameter Description
Index
[IPOutboundManipulation_Index]
Defines an index number for the new table record.
Manipulation Name
CLI: manipulation-name
[IPOutboundManipulation_Manipu
lationName]
Defines an arbitrary name to easily identify the manipulation
name.
The valid value is a string of up to 20 characters. By default,
no value is defined.
Matching Characteristics - Rule
Additional Manipulation
CLI: is-additional-manipulation
[IPOutboundManipulation_IsAddit
ionalManipulation]
Determines whether additional manipulation is done for the
table entry rule listed directly above it.
[0] No = (Default) Regular manipulation rule - not done in
addition to the rule above it.
[1] Yes = If the previous table row entry rule matched the
call, consider this row entry as a match as well and perform
the manipulation specified by this rule.
Note: Additional manipulation can only be done on a different
item (source URI, destination URI, or calling name) to the rule
configured in the row above (configured by the 'Manipulated
URI' parameter).
